Test Date: 2016-02-25 10:07
Analysis date: 2016-05-26 11:19
Analysis date: 2016-05-26 11:19
M2168 XRayHRQualification
Summary
| Module | Module | M2168 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 14/2/0 | |
| PixelDefects | Total Pixel Defects | 296 | |
| BumpBondingDefects | Bump Bonding Defects | 294 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.27 | % |
| Noise | Mean Noise | 162 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
B
|
45 | 0 | 99.87 | 99.10 | 0.35 | 21.6 | 64.7 | 45 | 0/0 | 0 | 1935 | 166 | 0 |
|
Chip 1
|
A
|
23 | 0 | 99.85 | 99.04 | 0.43 | 21.4 | 65.3 | 23 | 0/0 | 0 | 1965 | 157 | 0 |
|
Chip 2
|
A
|
27 | 0 | 99.89 | 99.35 | 0.28 | 18.5 | 57.0 | 27 | 0/0 | 0 | 1929 | 154 | 0 |
|
Chip 3
|
A
|
32 | 0 | 99.90 | 99.37 | 0.44 | 38.7 | 112.8 | 32 | 0/0 | 0 | 2052 | 172 | 0 |
|
Chip 4
|
A
|
12 | 0 | 99.88 | 99.37 | 0.41 | 38.0 | 111.8 | 12 | 0/0 | 0 | 2083 | 161 | 0 |
|
Chip 5
|
A
|
16 | 0 | 99.87 | 99.39 | 0.46 | 42.0 | 122.3 | 16 | 0/0 | 0 | 2102 | 157 | 0 |
|
Chip 6
|
A
|
8 | 0 | 99.89 | 99.38 | 0.51 | 41.5 | 121.8 | 8 | 0/0 | 0 | 2077 | 161 | 0 |
|
Chip 7
|
A
|
15 | 0 | 99.86 | 99.06 | 0.63 | 44.3 | 129.5 | 15 | 0/0 | 0 | 2105 | 162 | 0 |
|
Chip 8
|
A
|
23 | 0 | 99.89 | 99.37 | 0.56 | 43.0 | 127.2 | 23 | 0/0 | 0 | 2065 | 161 | 0 |
|
Chip 9
|
A
|
5 | 0 | 99.86 | 99.08 | 0.74 | 45.5 | 132.6 | 4 | 0/0 | 0 | 2050 | 162 | 1 |
|
Chip 10
|
A
|
3 | 0 | 99.88 | 99.36 | 0.68 | 54.6 | 157.2 | 3 | 0/0 | 0 | 2144 | 175 | 0 |
|
Chip 11
|
A
|
4 | 0 | 99.88 | 99.36 | 0.5 | 40.2 | 118.5 | 4 | 0/0 | 0 | 2079 | 160 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.35 | 0.45 | 37.0 | 109.2 | 0 | 0/0 | 0 | 2033 | 166 | 0 |
|
Chip 13
|
A
|
16 | 0 | 99.87 | 99.35 | 0.42 | 22.3 | 67.5 | 16 | 0/0 | 0 | 1954 | 159 | 0 |
|
Chip 14
|
A
|
19 | 0 | 99.85 | 99.06 | 0.57 | 24.8 | 74.9 | 19 | 0/0 | 0 | 1970 | 161 | 0 |
|
Chip 15
|
B
|
48 | 0 | 99.87 | 99.31 | 0.56 | 26.8 | 79.2 | 47 | 0/0 | 0 | 1931 | 164 | 1 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-02-25 | |
| TestTime | Test Time | 10:07 | |
| TestDuration | Duration | 1:27:47 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
