Test Date: 2016-02-25 10:07
Analysis date: 2016-05-26 11:00
Analysis date: 2016-05-26 11:00
M2165 XRayHRQualification
Summary
| Module | Module | M2165 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 195 | |
| BumpBondingDefects | Bump Bonding Defects | 31 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.25 | % |
| Noise | Mean Noise | 172 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
19 | 0 | 99.86 | 99.19 | 0.48 | 25.4 | 75.1 | 19 | 0/0 | 0 | 1966 | 172 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.86 | 98.97 | 0.54 | 25.0 | 74.9 | 0 | 0/0 | 0 | 1958 | 164 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.85 | 99.36 | 0.61 | 23.7 | 71.6 | 0 | 0/0 | 0 | 1949 | 176 | 0 |
|
Chip 3
|
A
|
2 | 0 | 99.88 | 99.33 | 0.52 | 38.0 | 111.4 | 2 | 0/0 | 0 | 2039 | 166 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.88 | 99.34 | 0.38 | 46.4 | 135.5 | 0 | 0/0 | 0 | 2112 | 186 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.33 | 0.54 | 49.9 | 144.1 | 0 | 0/0 | 0 | 2114 | 169 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.88 | 99.38 | 0.45 | 47.9 | 138.6 | 0 | 0/0 | 0 | 2132 | 169 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.89 | 99.37 | 0.54 | 50.5 | 145.7 | 0 | 0/0 | 0 | 2124 | 174 | 0 |
|
Chip 8
|
C
|
168 | 1 | 99.88 | 99.37 | 0.39 | 40.6 | 119.6 | 8 | 0/0 | 0 | 2044 | 156 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.89 | 99.37 | 0.44 | 43.2 | 126.5 | 0 | 0/0 | 0 | 2088 | 172 | 0 |
|
Chip 10
|
A
|
3 | 0 | 99.87 | 99.29 | 0.74 | 50.0 | 143.9 | 1 | 0/0 | 0 | 2107 | 180 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.11 | 0.68 | 40.6 | 119.8 | 0 | 0/0 | 0 | 2085 | 177 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.88 | 99.36 | 0.34 | 33.9 | 100.3 | 0 | 0/0 | 0 | 2046 | 170 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.86 | 99.10 | 0.4 | 21.1 | 64.1 | 0 | 0/0 | 0 | 1938 | 168 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.83 | 99.02 | 0.46 | 22.9 | 68.8 | 0 | 0/0 | 0 | 1914 | 173 | 1 |
|
Chip 15
|
A
|
1 | 0 | 99.86 | 99.09 | 0.69 | 24.5 | 72.7 | 1 | 0/0 | 0 | 1957 | 184 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-02-25 | |
| TestTime | Test Time | 10:07 | |
| TestDuration | Duration | 1:27:47 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
