Test Date: 2016-02-24 09:58
Analysis date: 2016-05-26 10:53
Analysis date: 2016-05-26 10:53
M2164 XRayHRQualification
Summary
| Module | Module | M2164 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 10 | |
| BumpBondingDefects | Bump Bonding Defects | 6 | |
| NoisyPixels | Noisy Pixels | 3 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.32 | % |
| Noise | Mean Noise | 174 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.89 | 99.37 | 0.43 | 23.2 | 69.6 | 0 | 0/0 | 0 | 1936 | 182 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.87 | 99.18 | 0.41 | 21.2 | 64.5 | 1 | 0/0 | 0 | 1932 | 170 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.87 | 99.37 | 0.39 | 18.8 | 57.6 | 0 | 0/0 | 0 | 1914 | 166 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.85 | 99.04 | 0.42 | 35.8 | 105.5 | 0 | 0/0 | 0 | 2044 | 170 | 0 |
|
Chip 4
|
A
|
3 | 0 | 99.84 | 99.39 | 0.76 | 40.4 | 118.3 | 0 | 0/0 | 0 | 1986 | 175 | 3 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.40 | 0.67 | 47.9 | 138.1 | 0 | 0/0 | 0 | 2125 | 170 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.31 | 0.55 | 45.9 | 133.7 | 0 | 0/0 | 0 | 2108 | 180 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.88 | 99.42 | 0.54 | 46.8 | 136.0 | 0 | 0/0 | 0 | 2098 | 184 | 0 |
|
Chip 8
|
A
|
2 | 0 | 99.88 | 99.43 | 0.68 | 46.9 | 136.6 | 2 | 0/0 | 0 | 2128 | 171 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.88 | 99.44 | 0.59 | 50.2 | 145.4 | 0 | 0/0 | 0 | 2152 | 173 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.90 | 99.38 | 0.45 | 55.2 | 158.5 | 0 | 0/0 | 0 | 2180 | 170 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.89 | 99.41 | 0.4 | 45.1 | 131.1 | 0 | 0/0 | 0 | 2109 | 180 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.84 | 99.14 | 0.59 | 40.0 | 117.8 | 0 | 0/0 | 0 | 2063 | 175 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.08 | 0.38 | 22.2 | 67.6 | 0 | 0/0 | 0 | 1955 | 169 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.89 | 99.36 | 0.33 | 23.8 | 71.9 | 1 | 0/0 | 0 | 1965 | 175 | 0 |
|
Chip 15
|
A
|
2 | 0 | 99.88 | 99.33 | 0.39 | 23.1 | 68.9 | 2 | 0/0 | 0 | 1948 | 168 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-02-24 | |
| TestTime | Test Time | 09:58 | |
| TestDuration | Duration | 1:26:39 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 21 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
