Test Date: 2016-02-11 16:37
Analysis date: 2016-05-26 10:09
Analysis date: 2016-05-26 10:09
M2156 XRayHRQualification
Summary
| Module | Module | M2156 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 59 | |
| BumpBondingDefects | Bump Bonding Defects | 57 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.26 | % |
| Noise | Mean Noise | 166 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
18 | 0 | 99.88 | 99.33 | 0.29 | 68.4 | 18 | 22.9 | 0/0 | 0 | 1938 | 158 | 0 |
|
Chip 1
|
A
|
10 | 0 | 99.85 | 99.02 | 0.53 | 71.7 | 10 | 23.7 | 0/0 | 0 | 1943 | 159 | 0 |
|
Chip 2
|
A
|
7 | 0 | 99.86 | 99.06 | 0.33 | 73.0 | 7 | 24.1 | 0/0 | 0 | 1945 | 175 | 0 |
|
Chip 3
|
A
|
7 | 0 | 99.86 | 99.34 | 1.0 | 125.7 | 7 | 43.5 | 0/0 | 0 | 2103 | 175 | 0 |
|
Chip 4
|
A
|
2 | 0 | 99.85 | 99.09 | 0.76 | 129.8 | 2 | 44.8 | 0/0 | 0 | 2102 | 171 | 0 |
|
Chip 5
|
A
|
1 | 0 | 99.87 | 99.39 | 0.57 | 155.6 | 1 | 54.7 | 0/0 | 0 | 2146 | 169 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.89 | 99.42 | 0.34 | 163.2 | 0 | 57.0 | 0/0 | 0 | 2155 | 173 | 1 |
|
Chip 7
|
A
|
3 | 0 | 99.86 | 99.31 | 1.05 | 159.2 | 3 | 55.7 | 0/0 | 0 | 2178 | 162 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.89 | 99.37 | 0.56 | 134.5 | 0 | 46.8 | 0/0 | 0 | 2093 | 159 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.37 | 0.4 | 132.4 | 0 | 46.0 | 0/0 | 0 | 2110 | 164 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.89 | 99.31 | 0.69 | 148.3 | 1 | 52.3 | 0/0 | 0 | 2148 | 167 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.89 | 99.34 | 0.47 | 125.2 | 0 | 43.1 | 0/0 | 0 | 2081 | 176 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.88 | 99.30 | 0.52 | 94.6 | 0 | 31.6 | 0/0 | 0 | 1972 | 153 | 1 |
|
Chip 13
|
A
|
0 | 0 | 99.88 | 99.27 | 0.41 | 59.4 | 0 | 19.4 | 0/0 | 0 | 1931 | 161 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 98.95 | 0.45 | 69.2 | 0 | 23.0 | 0/0 | 0 | 1941 | 168 | 0 |
|
Chip 15
|
A
|
8 | 0 | 99.87 | 99.32 | 0.43 | 65.8 | 8 | 22.1 | 0/0 | 0 | 1947 | 165 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-02-11 | |
| TestTime | Test Time | 16:37 | |
| TestDuration | Duration | 1:27:53 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 17 | |
| nWarnings | # Warnings | 5 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 5 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 1 | |
| message_readback_count | Readback start marker | 4 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
