Test Date: 2016-02-09 11:35
Analysis date: 2016-05-26 09:51
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
48.2165625 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
48.2165625 |
|
| medianSlope |
median Slope |
48.387 |
|
| minSlope |
min Slope |
44.189 |
|
| maxSlope |
max Slope |
51.73 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-40.514 |
|
| medianOffset |
median Offset |
-16.1335 |
|
| minOffset |
min Offset |
-184.106 |
|
| maxOffset |
max Offset |
110.505 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
4.0375625 |
|
| medianchi2 |
median chi2 |
1.9525 |
|
| minchi2 |
min chi2 |
0.013 |
|
| maxchi2 |
max chi2 |
14.09 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
47.0 e- / Vcal
|
0.1 e- / Vcal
|
40.4 e-
|
8.4 e-
|
|
1
|
51.0 e- / Vcal
|
0.1 e- / Vcal
|
-14.4 e-
|
8.2 e-
|
|
2
|
49.6 e- / Vcal
|
0.2 e- / Vcal
|
-4.6 e-
|
23.7 e-
|
|
3
|
51.7 e- / Vcal
|
0.1 e- / Vcal
|
-127.4 e-
|
8.7 e-
|
|
4
|
50.2 e- / Vcal
|
0.2 e- / Vcal
|
-55.2 e-
|
19.0 e-
|
|
5
|
47.7 e- / Vcal
|
0.2 e- / Vcal
|
23.7 e-
|
18.3 e-
|
|
6
|
48.9 e- / Vcal
|
0.1 e- / Vcal
|
-137.2 e-
|
9.0 e-
|
|
7
|
49.7 e- / Vcal
|
0.1 e- / Vcal
|
-1.2 e-
|
8.0 e-
|
|
8
|
44.2 e- / Vcal
|
0.1 e- / Vcal
|
-7.5 e-
|
17.6 e-
|
|
9
|
45.6 e- / Vcal
|
0.1 e- / Vcal
|
-17.9 e-
|
8.0 e-
|
|
10
|
49.6 e- / Vcal
|
0.2 e- / Vcal
|
-105.1 e-
|
17.5 e-
|
|
11
|
46.8 e- / Vcal
|
0.1 e- / Vcal
|
-137.9 e-
|
8.5 e-
|
|
12
|
46.4 e- / Vcal
|
0.1 e- / Vcal
|
-184.1 e-
|
18.5 e-
|
|
13
|
48.0 e- / Vcal
|
0.1 e- / Vcal
|
27.2 e-
|
8.6 e-
|
|
14
|
48.7 e- / Vcal
|
0.2 e- / Vcal
|
-57.5 e-
|
18.9 e-
|
|
15
|
46.3 e- / Vcal
|
0.2 e- / Vcal
|
110.5 e-
|
18.8 e-
|
|
Average
|
48.2 e- / Vcal
|
|
-40.5 e-
|
|
|
Median
|
93.9 e- / Vcal
|
|
-8.7 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
