Test Date: 2016-02-08 11:28
Analysis date: 2016-05-26 09:14
Analysis date: 2016-05-26 09:14
M2147 XRayHRQualification
Summary
| Module | Module | M2147 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 10 | |
| BumpBondingDefects | Bump Bonding Defects | 10 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.27 | % |
| Noise | Mean Noise | 167 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.89 | 99.35 | 0.29 | 19.9 | 61.6 | 1 | 0/0 | 0 | 1934 | 161 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.85 | 99.09 | 0.48 | 19.7 | 61.5 | 0 | 0/0 | 0 | 1911 | 161 | 0 |
|
Chip 2
|
A
|
1 | 0 | 99.89 | 99.33 | 0.34 | 18.7 | 58.2 | 1 | 0/0 | 0 | 1896 | 169 | 0 |
|
Chip 3
|
A
|
2 | 0 | 99.86 | 99.27 | 1.55 | 31.3 | 94.6 | 2 | 0/0 | 0 | 2018 | 156 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.84 | 99.10 | 0.69 | 38.4 | 114.2 | 0 | 0/0 | 0 | 2067 | 174 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.09 | 0.59 | 40.1 | 118.6 | 0 | 0/0 | 0 | 2048 | 161 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.40 | 0.29 | 38.4 | 114.1 | 0 | 0/0 | 0 | 2044 | 163 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.88 | 99.38 | 0.41 | 38.8 | 115.4 | 0 | 0/0 | 0 | 2048 | 167 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.89 | 99.35 | 0.63 | 45.0 | 132.5 | 0 | 0/0 | 0 | 2090 | 167 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.34 | 0.55 | 46.5 | 136.3 | 0 | 0/0 | 0 | 2084 | 171 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.40 | 0.45 | 49.0 | 142.0 | 0 | 0/0 | 0 | 2133 | 168 | 0 |
|
Chip 11
|
A
|
2 | 0 | 99.90 | 99.40 | 0.56 | 42.5 | 125.7 | 2 | 0/0 | 0 | 2096 | 170 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.87 | 99.25 | 0.66 | 35.8 | 106.8 | 1 | 0/0 | 0 | 2057 | 165 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.87 | 99.42 | 0.47 | 19.1 | 60.0 | 0 | 0/0 | 0 | 1926 | 160 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.86 | 99.14 | 0.61 | 24.8 | 76.3 | 0 | 0/0 | 0 | 1980 | 187 | 0 |
|
Chip 15
|
A
|
3 | 0 | 99.86 | 98.97 | 0.52 | 21.3 | 65.8 | 3 | 0/0 | 0 | 1910 | 168 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-02-08 | |
| TestTime | Test Time | 11:28 | |
| TestDuration | Duration | 1:35:46 | |
| pXar | pXar version | prod-12 | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
