Test Date: 2016-02-08 11:28
Analysis date: 2016-05-26 08:56
Analysis date: 2016-05-26 08:56
M2144 XRayHRQualification
Summary
| Module | Module | M2144 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 13 | |
| BumpBondingDefects | Bump Bonding Defects | 12 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.26 | % |
| Noise | Mean Noise | 169 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
6 | 0 | 99.88 | 99.32 | 0.41 | 23.5 | 71.1 | 6 | 0/0 | 0 | 1955 | 165 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.07 | 0.54 | 24.0 | 73.3 | 0 | 0/0 | 0 | 1972 | 163 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.26 | 0.32 | 20.2 | 63.0 | 0 | 0/0 | 0 | 1921 | 161 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.89 | 99.36 | 0.45 | 40.3 | 118.3 | 0 | 0/0 | 0 | 2096 | 171 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.88 | 99.38 | 0.52 | 41.8 | 123.3 | 0 | 0/0 | 0 | 2091 | 171 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.89 | 99.37 | 0.59 | 53.1 | 151.6 | 0 | 0/0 | 0 | 2139 | 168 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.88 | 99.34 | 0.66 | 53.9 | 156.0 | 1 | 0/0 | 0 | 2148 | 175 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.89 | 99.38 | 0.7 | 56.5 | 163.3 | 0 | 0/0 | 0 | 2136 | 172 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.37 | 0.58 | 49.4 | 143.0 | 0 | 0/0 | 0 | 2129 | 172 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.01 | 0.69 | 45.3 | 131.5 | 0 | 0/0 | 0 | 2070 | 168 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.34 | 0.48 | 44.6 | 129.3 | 0 | 0/0 | 0 | 2097 | 168 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.85 | 99.11 | 0.68 | 36.4 | 108.0 | 1 | 0/0 | 0 | 2060 | 165 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.88 | 99.34 | 0.8 | 36.5 | 108.7 | 0 | 0/0 | 0 | 2040 | 175 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.01 | 0.38 | 21.3 | 65.5 | 0 | 0/0 | 0 | 1955 | 169 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.87 | 99.19 | 0.4 | 22.4 | 68.8 | 0 | 0/0 | 0 | 1945 | 165 | 0 |
|
Chip 15
|
A
|
4 | 0 | 99.87 | 99.31 | 0.54 | 23.8 | 71.8 | 4 | 0/0 | 0 | 1956 | 172 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-02-08 | |
| TestTime | Test Time | 11:28 | |
| TestDuration | Duration | 1:35:46 | |
| pXar | pXar version | prod-12 | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 8 | |
| nErrors | # Errors | 14725 | |
| nWarnings | # Warnings | 16 | |
| channel_0_count | Channel 0 | 26 | |
| channel_1_count | Channel 1 | 25 | |
| channel_2_count | Channel 2 | 47 | |
| channel_3_count | Channel 3 | 48 | |
| message_eventid_count | Event ID mismatch | 30 | |
| message_notokenpass_count | has NoTokenPass | 24 | |
| message_missingevents_count | Missing Event criticals | 4 | |
| message_tokenchain_count | Token Chain Length | 76 | |
| message_datasize_count | Data size criticals | 4 | |
| message_readback_count | Readback start marker | 16 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
