M2143 XRayHRQualification
Summary
| Module | Module | M2143 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 133 | |
| BumpBondingDefects | Bump Bonding Defects | 122 | |
| NoisyPixels | Noisy Pixels | 11 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.34 | % |
| Noise | Mean Noise | 169 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
15 | 0 | 99.88 | 99.29 | 0.55 | 30.2 | 89.8 | 10 | 0/0 | 0 | 1828 | 171 | 5 |
|
Chip 1
|
A
|
8 | 0 | 99.86 | 99.32 | 0.66 | 30.2 | 91.0 | 8 | 0/0 | 0 | 2008 | 172 | 0 |
|
Chip 2
|
A
|
4 | 0 | 99.86 | 99.26 | 1.13 | 27.0 | 82.0 | 4 | 0/0 | 0 | 1947 | 164 | 1 |
|
Chip 3
|
A
|
2 | 0 | 99.87 | 99.35 | 0.48 | 52.2 | 151.8 | 0 | 0/0 | 0 | 2129 | 170 | 2 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.33 | 0.87 | 48.1 | 141.2 | 0 | 0/0 | 0 | 2122 | 162 | 0 |
|
Chip 5
|
A
|
7 | 0 | 99.89 | 99.37 | 0.4 | 66.2 | 190.5 | 7 | 0/0 | 0 | 2228 | 165 | 0 |
|
Chip 6
|
A
|
6 | 0 | 99.86 | 99.36 | 0.8 | 58.9 | 170.3 | 6 | 0/0 | 0 | 2184 | 164 | 0 |
|
Chip 7
|
A
|
2 | 0 | 99.87 | 99.36 | 0.41 | 60.7 | 175.2 | 2 | 0/0 | 0 | 2205 | 162 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.88 | 99.41 | 0.53 | 64.9 | 188.2 | 1 | 0/0 | 0 | 2181 | 173 | 0 |
|
Chip 9
|
A
|
14 | 0 | 99.87 | 99.38 | 1.2 | 61.5 | 178.7 | 10 | 0/0 | 0 | 2192 | 166 | 3 |
|
Chip 10
|
A
|
3 | 0 | 99.88 | 99.37 | 0.57 | 58.5 | 168.7 | 3 | 0/0 | 0 | 2162 | 160 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.89 | 99.40 | 0.58 | 54.7 | 159.3 | 1 | 0/0 | 0 | 2172 | 165 | 0 |
|
Chip 12
|
A
|
14 | 0 | 99.87 | 99.41 | 0.61 | 55.5 | 161.2 | 14 | 0/0 | 0 | 2166 | 183 | 0 |
|
Chip 13
|
A
|
9 | 0 | 99.84 | 99.35 | 0.6 | 30.6 | 93.5 | 9 | 0/0 | 0 | 2023 | 179 | 0 |
|
Chip 14
|
A
|
26 | 0 | 99.87 | 99.15 | 0.57 | 32.9 | 99.1 | 26 | 0/0 | 0 | 2016 | 175 | 0 |
|
Chip 15
|
A
|
21 | 0 | 99.88 | 99.32 | 0.64 | 30.7 | 91.7 | 21 | 0/0 | 0 | 2019 | 175 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-01-22 | |
| TestTime | Test Time | 13:53 | |
| TestDuration | Duration | 0:54:42 | |
| pXar | pXar version | prod-12 | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
