Test Date: 2016-01-13 15:45
Analysis date: 2016-05-26 08:32
Analysis date: 2016-05-26 08:32
M2140 XRayHRQualification
Summary
| Module | Module | M2140 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 11 | |
| BumpBondingDefects | Bump Bonding Defects | 11 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.31 | % |
| Noise | Mean Noise | 168 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
3 | 0 | 99.86 | 99.33 | 0.56 | 89.8 | 3 | 30.1 | 0/0 | 0 | 2010 | 173 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.87 | 99.31 | 0.39 | 89.8 | 1 | 29.6 | 0/0 | 0 | 1999 | 166 | 0 |
|
Chip 2
|
A
|
1 | 0 | 99.86 | 99.21 | 0.47 | 81.9 | 1 | 26.7 | 0/0 | 0 | 1964 | 162 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.31 | 0.68 | 147.3 | 0 | 50.5 | 0/0 | 0 | 2144 | 166 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.88 | 99.39 | 0.5 | 147.2 | 0 | 50.5 | 0/0 | 0 | 2142 | 169 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.35 | 0.95 | 172.3 | 0 | 60.1 | 0/0 | 0 | 2182 | 161 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.34 | 0.69 | 160.9 | 0 | 55.7 | 0/0 | 0 | 2147 | 159 | 0 |
|
Chip 7
|
A
|
3 | 0 | 99.88 | 99.37 | 0.57 | 190.4 | 3 | 66.0 | 0/0 | 0 | 2211 | 167 | 0 |
|
Chip 8
|
A
|
2 | 0 | 99.85 | 99.27 | 0.74 | 189.5 | 2 | 65.5 | 0/0 | 0 | 2229 | 172 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.39 | 0.48 | 162.5 | 0 | 55.8 | 0/0 | 0 | 2167 | 162 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.36 | 0.86 | 192.6 | 0 | 67.3 | 0/0 | 0 | 2248 | 171 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.26 | 0.99 | 163.7 | 0 | 56.0 | 0/0 | 0 | 2201 | 177 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.84 | 99.08 | 0.69 | 140.2 | 0 | 47.6 | 0/0 | 0 | 2137 | 170 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.86 | 99.34 | 0.49 | 90.5 | 0 | 29.7 | 0/0 | 0 | 2013 | 175 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.88 | 99.31 | 0.64 | 89.4 | 0 | 29.3 | 0/0 | 0 | 2002 | 167 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.87 | 99.33 | 0.48 | 92.9 | 1 | 31.0 | 0/0 | 0 | 2009 | 171 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-01-13 | |
| TestTime | Test Time | 15:45 | |
| TestDuration | Duration | 1:33:0 | |
| pXar | pXar version | prod-12 | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 8 | |
| nErrors | # Errors | 1239 | |
| nWarnings | # Warnings | 22 | |
| channel_0_count | Channel 0 | 64 | |
| channel_1_count | Channel 1 | 69 | |
| channel_2_count | Channel 2 | 11 | |
| channel_3_count | Channel 3 | 5 | |
| message_eventid_count | Event ID mismatch | 22 | |
| message_notokenpass_count | has NoTokenPass | 11 | |
| message_missingevents_count | Missing Event criticals | 4 | |
| message_tokenchain_count | Token Chain Length | 94 | |
| message_datasize_count | Data size criticals | 4 | |
| message_readback_count | Readback start marker | 22 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
