Test Date: 2016-01-13 15:45
Analysis date: 2016-05-26 08:26
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
48.124375 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
48.124375 |
|
| medianSlope |
median Slope |
48.4695 |
|
| minSlope |
min Slope |
44.733 |
|
| maxSlope |
max Slope |
50.978 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-70.75825 |
|
| medianOffset |
median Offset |
-82.55 |
|
| minOffset |
min Offset |
-209.174 |
|
| maxOffset |
max Offset |
91.209 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
5.358875 |
|
| medianchi2 |
median chi2 |
2.4785 |
|
| minchi2 |
min chi2 |
0.003 |
|
| maxchi2 |
max chi2 |
32.481 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
46.7 e- / Vcal
|
0.1 e- / Vcal
|
-185.4 e-
|
6.3 e-
|
|
1
|
50.3 e- / Vcal
|
0.1 e- / Vcal
|
-156.3 e-
|
17.4 e-
|
|
2
|
46.6 e- / Vcal
|
0.1 e- / Vcal
|
91.2 e-
|
18.4 e-
|
|
3
|
47.2 e- / Vcal
|
0.1 e- / Vcal
|
39.5 e-
|
7.5 e-
|
|
4
|
45.1 e- / Vcal
|
0.1 e- / Vcal
|
5.1 e-
|
5.9 e-
|
|
5
|
44.7 e- / Vcal
|
0.1 e- / Vcal
|
-41.2 e-
|
6.6 e-
|
|
6
|
48.4 e- / Vcal
|
0.1 e- / Vcal
|
-17.9 e-
|
6.4 e-
|
|
7
|
49.3 e- / Vcal
|
0.1 e- / Vcal
|
-173.9 e-
|
6.6 e-
|
|
8
|
50.8 e- / Vcal
|
0.1 e- / Vcal
|
-93.2 e-
|
6.8 e-
|
|
9
|
50.5 e- / Vcal
|
0.1 e- / Vcal
|
-129.8 e-
|
8.2 e-
|
|
10
|
47.1 e- / Vcal
|
0.1 e- / Vcal
|
-45.1 e-
|
15.4 e-
|
|
11
|
49.1 e- / Vcal
|
0.1 e- / Vcal
|
-76.1 e-
|
7.3 e-
|
|
12
|
51.0 e- / Vcal
|
0.1 e- / Vcal
|
-99.2 e-
|
16.0 e-
|
|
13
|
49.7 e- / Vcal
|
0.1 e- / Vcal
|
-89.0 e-
|
8.3 e-
|
|
14
|
48.5 e- / Vcal
|
0.1 e- / Vcal
|
-209.2 e-
|
17.4 e-
|
|
15
|
45.0 e- / Vcal
|
0.1 e- / Vcal
|
48.2 e-
|
7.9 e-
|
|
Average
|
48.1 e- / Vcal
|
|
-70.8 e-
|
|
|
Median
|
100.1 e- / Vcal
|
|
-267.0 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
