Test Date: 2016-01-12 17:15
Analysis date: 2016-05-26 08:17
Analysis date: 2016-05-26 08:17
M2138 ModuleFulltestPxar_p17_1
Summary 1
| Module | Module | M2138 | |
| Grade | Grade | A | |
| ElectricalGrade | Electrical Grade | A | |
| IVGrade | IV Grade | A | |
| ManualGrade | Manual Grade | None | |
| PixelDefects | Pixel Defects - A/B/C | 118 - 16/0/0 | |
| DeadPixels | Dead Pixels | 3 | |
| AddressProblems | Address Problems | 0 | |
| ThresholdDefects | Threshold Defects | 3 | |
| MaskDefects | Mask Defects | 0 | |
| DeadBumps | Dead Bumps | 112 | |
| NoisyPixels | Noise Defects | 0 | |
| TrimProblems | Trim Problems | 0 | |
| PHGainDefects | PH Gain Defects | 1 | |
| PHPar1Defects | PH Parameter1 Defects | 0 |
Summary 2
| TestCenter | Test Center | ETH | |
| TestDate | Test Date | 2016-01-12 | |
| TestTime | Test Time | 17:15 | |
| TestDuration | Duration | 1:19:56 | |
| TempC | Temparature | 17 | °C |
| TBM1 | TBM1 | ok, 0xe8 0xed | |
| TBM2 | TBM2 | ok, 0x00 0xed | |
| PxarVersion | pXar | prod-12 | |
| DTB_FW | DTB FW | 4.5 | |
| ModuleIa | Module Ia | 382.7 | mA |
Summary 3
| Noise | Noise | 132.27 | e |
| NoiseROCs | Noise grades | 16/0/0 | |
| VcalThrWidth | Vcal Thr. Width | 44.09 | e |
| VcalThrWidthROCs | Vcal Thr. W. grades | 16/0/0 | |
| RelGainWidth | Rel. Gain Width | 0.03 | % |
| RelGainWidthROCs | Rel. Gain W. grades | 16/0/0 | |
| PedestalSpread | Pedestal Spread | 1207.09 | e |
| PedestalSpreadROCs | Ped. Spread grades | 16/0/0 | |
| Parameter1 | Parameter1 | 0.71 | |
| Parameter1ROCs | Par1 grades | 16/0/0 | |
| CurrentAtVoltage150V | I(150 V) | 1.22 | μA |
| CurrentVariation | I(150 V) / I(100 V) | 1.15 |
IVCurve
Digital Current
| Duration | Duration | 1:19:56 | |
| MinCurrent | min. Current | 0.38 | A |
| MaxCurrent | max. Current | 0.489 | A |
Analog Current
| Duration | Duration | 1:19:56 | |
| MinCurrent | min. Current | 0.076 | A |
| MaxCurrent | max. Current | 0.387 | A |
| ModuleIa | Module Ia | 382.7 | mA |
IanaLoss
| IanaLossProblems | Iana problems | No | |
| Mean | mean | 18.60 | |
| Min | min | 18.50 | |
| Max | max | 19.30 | |
| NROCsNotProgrammable | ROCs not programmable | 0 |
Temperature
| Temperature | Temp. while test | 17.00 +/- 0.09 | °C |
| Duration | Duration of test | 0:09:34 |
Summary ROCs
| ROC | Grade | Total | Dead | Mask | Bumps | Trim(Bits) | Address | Noise | Thresh | Gain | Ped | Par1 | Mean noise | Thr [e-] | Thr width | Rel gain width | Ped spread |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Chip 0 |
A
|
14
|
0
|
0
|
13
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
139.02
|
1748 |
46
|
0.027
|
1346
|
| Chip 1 |
A
|
18
|
0
|
0
|
18
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
117.96
|
1750 |
42
|
0.036
|
1158
|
| Chip 2 |
A
|
9
|
0
|
0
|
9
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
134.69
|
1749 |
43
|
0.025
|
1164
|
| Chip 3 |
A
|
5
|
0
|
0
|
4
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
127.28
|
1750 |
45
|
0.035
|
1157
|
| Chip 4 |
A
|
1
|
0
|
0
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
133.06
|
1746 |
44
|
0.036
|
1276
|
| Chip 5 |
A
|
5
|
0
|
0
|
5
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
136.70
|
1750 |
43
|
0.032
|
960
|
| Chip 6 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
134.34
|
1748 |
45
|
0.028
|
1187
|
| Chip 7 |
A
|
5
|
0
|
0
|
4
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
125.81
|
1749 |
46
|
0.028
|
1368
|
| Chip 8 |
A
|
6
|
0
|
0
|
6
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
138.36
|
1749 |
43
|
0.028
|
1180
|
| Chip 9 |
A
|
15
|
1
|
0
|
14
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
129.44
|
1747 |
43
|
0.031
|
1318
|
| Chip 10 |
A
|
7
|
0
|
0
|
7
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
137.21
|
1748 |
42
|
0.024
|
1092
|
| Chip 11 |
A
|
4
|
0
|
0
|
4
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
129.28
|
1750 |
43
|
0.023
|
1256
|
| Chip 12 |
A
|
12
|
0
|
0
|
12
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
132.25
|
1749 |
45
|
0.028
|
1224
|
| Chip 13 |
A
|
2
|
0
|
0
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
136.58
|
1749 |
45
|
0.025
|
1138
|
| Chip 14 |
A
|
5
|
0
|
0
|
5
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
136.56
|
1750 |
46
|
0.026
|
1282
|
| Chip 15 |
A
|
10
|
2
|
0
|
8
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
127.72
|
1753 |
46
|
0.027
|
1208
|
GradingParameters
| ModifiedGrading | Modified Grading | True | |
| GradingParameters_leakageCurrentRatioB | leakageCurrentRatioB | 20 => -111 |
TBM
| nTBMs | n | 1 | |
| TBMType | Type | tbm09c | |
| Core0a_basea | Core 0a base a | 0xed | |
| Core0a_basee | Core 0a base e | 0xe8 | |
| Core0b_basea | Core 0b base a | 0xed | |
| Core0b_basee | Core 0b base e | 0x00 | |
| RocDelay_Ch0 | Roc Delay Ch0 | 5 | |
| RocDelay_Ch1 | Roc Delay Ch1 | 5 | |
| RocDelay_Ch2 | Roc Delay Ch2 | 5 | |
| RocDelay_Ch3 | Roc Delay Ch3 | 5 | |
| Phase400 | Phase 400 | 2 | |
| Phase160 | Phase 160 | 7 |
Errors
| nCriticals | # Criticals | 3 | |
| nErrors | # Errors | 474 | |
| nWarnings | # Warnings | 36 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 257 | |
| channel_3_count | Channel 3 | 253 | |
| message_eventid_count | Event ID mismatch | 206 | |
| message_readback_count | Readback start marker | 36 | |
| message_tokenchain_count | Token Chain Length | 162 | |
| message_notokenpass_count | has NoTokenPass | 106 | |
| message_missingevents_count | Missing Event criticals | 2 | |
| message_datasize_count | Data size criticals | 1 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
