Test Date: 2015-12-16 10:27
Analysis date: 2016-05-26 07:12
Analysis date: 2016-05-26 07:12
M2126 XRayHRQualification
Summary
| Module | Module | M2126 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 20 | |
| BumpBondingDefects | Bump Bonding Defects | 16 | |
| NoisyPixels | Noisy Pixels | 4 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.30 | % |
| Noise | Mean Noise | 162 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
2 | 0 | 99.87 | 99.28 | 0.51 | 31.4 | 92.6 | 2 | 0/0 | 0 | 2005 | 170 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.86 | 99.15 | 0.69 | 29.8 | 89.8 | 0 | 0/0 | 0 | 1998 | 163 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.84 | 98.94 | 0.64 | 28.1 | 85.2 | 0 | 0/0 | 0 | 1977 | 161 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.86 | 99.33 | 0.53 | 48.9 | 141.7 | 0 | 0/0 | 0 | 2122 | 162 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.88 | 99.34 | 0.61 | 47.5 | 139.3 | 1 | 0/0 | 0 | 2111 | 160 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.32 | 1.18 | 58.1 | 166.9 | 0 | 0/0 | 0 | 2182 | 162 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.87 | 99.37 | 0.59 | 52.5 | 152.8 | 0 | 0/0 | 0 | 2129 | 155 | 1 |
|
Chip 7
|
A
|
1 | 0 | 99.87 | 99.31 | 1.42 | 58.0 | 168.2 | 0 | 0/0 | 0 | 2148 | 154 | 1 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.41 | 0.8 | 61.7 | 177.6 | 0 | 0/0 | 0 | 2230 | 163 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.89 | 99.37 | 0.68 | 54.0 | 155.9 | 0 | 0/0 | 0 | 2148 | 154 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.89 | 99.37 | 0.58 | 58.9 | 167.3 | 0 | 0/0 | 0 | 2194 | 160 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.89 | 99.35 | 0.48 | 44.7 | 132.4 | 0 | 0/0 | 0 | 2102 | 152 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.85 | 99.22 | 0.72 | 47.7 | 137.8 | 0 | 0/0 | 0 | 2114 | 169 | 0 |
|
Chip 13
|
A
|
3 | 0 | 99.87 | 99.30 | 0.4 | 26.1 | 79.5 | 3 | 0/0 | 0 | 1994 | 160 | 0 |
|
Chip 14
|
A
|
5 | 0 | 99.87 | 99.36 | 0.41 | 31.5 | 94.0 | 3 | 0/0 | 0 | 1967 | 176 | 2 |
|
Chip 15
|
A
|
7 | 0 | 99.89 | 99.37 | 0.47 | 30.5 | 89.2 | 7 | 0/0 | 0 | 1986 | 174 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-12-16 | |
| TestTime | Test Time | 10:27 | |
| TestDuration | Duration | 2:36:22 | |
| pXar | pXar version | prod-12 | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 9 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 1 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 1 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
