Test Date: 2015-12-16 10:27
Analysis date: 2016-05-26 07:06
Analysis date: 2016-05-26 07:06
M2125 XRayHRQualification
Summary
| Module | Module | M2125 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 60 | |
| BumpBondingDefects | Bump Bonding Defects | 56 | |
| NoisyPixels | Noisy Pixels | 4 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.24 | % |
| Noise | Mean Noise | 159 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
8 | 0 | 99.86 | 99.14 | 0.6 | 23.9 | 71.1 | 8 | 0/0 | 0 | 1988 | 165 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.86 | 99.27 | 1.36 | 27.6 | 82.6 | 0 | 0/0 | 0 | 2004 | 184 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.03 | 0.42 | 21.1 | 64.7 | 0 | 0/0 | 0 | 1962 | 153 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.86 | 99.33 | 0.57 | 36.7 | 108.0 | 0 | 0/0 | 0 | 2083 | 153 | 0 |
|
Chip 4
|
A
|
14 | 0 | 99.88 | 99.35 | 0.59 | 44.8 | 130.5 | 13 | 0/0 | 0 | 2094 | 170 | 1 |
|
Chip 5
|
A
|
2 | 0 | 99.89 | 99.35 | 0.41 | 54.9 | 156.7 | 2 | 0/0 | 0 | 2181 | 156 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.33 | 0.75 | 50.5 | 145.2 | 0 | 0/0 | 0 | 2176 | 158 | 0 |
|
Chip 7
|
A
|
2 | 0 | 99.90 | 99.33 | 0.6 | 61.1 | 175.9 | 1 | 0/0 | 0 | 2192 | 166 | 1 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.33 | 0.49 | 45.8 | 132.7 | 0 | 0/0 | 0 | 2125 | 148 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.32 | 0.5 | 47.0 | 135.8 | 0 | 0/0 | 0 | 2147 | 153 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.32 | 0.52 | 49.8 | 142.9 | 0 | 0/0 | 0 | 2156 | 155 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.28 | 0.46 | 37.9 | 111.2 | 0 | 0/0 | 0 | 2085 | 148 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.34 | 0.38 | 36.2 | 106.4 | 0 | 0/0 | 0 | 2072 | 162 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.85 | 99.04 | 0.31 | 18.3 | 56.3 | 0 | 0/0 | 0 | 1957 | 145 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 99.02 | 0.49 | 22.2 | 67.2 | 0 | 0/0 | 0 | 1976 | 162 | 0 |
|
Chip 15
|
A
|
34 | 0 | 99.85 | 99.12 | 0.51 | 20.8 | 62.8 | 32 | 0/0 | 0 | 1871 | 169 | 2 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-12-16 | |
| TestTime | Test Time | 10:27 | |
| TestDuration | Duration | 2:36:22 | |
| pXar | pXar version | prod-12 | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 56 | |
| nWarnings | # Warnings | 4 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 8 | |
| channel_3_count | Channel 3 | 4 | |
| message_eventid_count | Event ID mismatch | 4 | |
| message_tokenchain_count | Token Chain Length | 4 | |
| message_readback_count | Readback start marker | 4 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
