Test Date: 2015-12-08 13:49
Analysis date: 2016-05-26 07:00
Analysis date: 2016-05-26 07:00
M2124 XRayHRQualification
Summary
| Module | Module | M2124 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 7 | |
| BumpBondingDefects | Bump Bonding Defects | 6 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.27 | % |
| Noise | Mean Noise | 169 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
5 | 0 | 99.85 | 98.97 | 0.5 | 64.3 | 5 | 21.4 | 0/0 | 0 | 1911 | 167 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.88 | 99.31 | 0.4 | 66.3 | 0 | 21.9 | 0/0 | 0 | 1935 | 167 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.87 | 99.29 | 0.39 | 56.5 | 0 | 18.3 | 0/0 | 0 | 1898 | 160 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.34 | 0.45 | 102.1 | 0 | 34.8 | 0/0 | 0 | 2016 | 169 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.88 | 99.33 | 0.58 | 117.6 | 0 | 40.4 | 0/0 | 0 | 2052 | 169 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.36 | 0.45 | 138.4 | 0 | 48.4 | 0/0 | 0 | 2102 | 171 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.40 | 0.52 | 129.6 | 0 | 45.2 | 0/0 | 0 | 2076 | 171 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.88 | 99.32 | 0.74 | 129.3 | 0 | 44.6 | 0/0 | 0 | 2063 | 161 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.37 | 0.39 | 130.7 | 0 | 44.9 | 0/0 | 0 | 2077 | 162 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.32 | 1.55 | 146.2 | 0 | 51.0 | 0/0 | 0 | 2117 | 171 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.33 | 0.48 | 144.3 | 0 | 50.1 | 0/0 | 0 | 2121 | 167 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.87 | 99.32 | 0.72 | 125.3 | 1 | 43.1 | 0/0 | 0 | 2085 | 170 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.85 | 99.24 | 1.49 | 116.2 | 0 | 39.7 | 0/0 | 0 | 2038 | 175 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.06 | 0.45 | 67.8 | 0 | 22.4 | 0/0 | 0 | 1922 | 170 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.82 | 98.98 | 1.14 | 76.7 | 0 | 25.6 | 0/0 | 0 | 1934 | 178 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.88 | 99.33 | 0.38 | 72.3 | 0 | 24.3 | 0/0 | 0 | 1933 | 181 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-12-08 | |
| TestTime | Test Time | 13:49 | |
| TestDuration | Duration | 1:40:25 | |
| pXar | pXar version | prod-12 | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
