Module | Module | M2122 | |
Grade | Grade | A | |
ElectricalGrade | Electrical Grade | A | |
IVGrade | IV Grade | None | |
ManualGrade | Manual Grade | None | |
PixelDefects | Pixel Defects - A/B/C | 17 - 16/0/0 | |
DeadPixels | Dead Pixels | 0 | |
AddressProblems | Address Problems | 0 | |
ThresholdDefects | Threshold Defects | 9 | |
MaskDefects | Mask Defects | 0 | |
DeadBumps | Dead Bumps | 8 | |
NoisyPixels | Noise Defects | 0 | |
TrimProblems | Trim Problems | 0 | |
PHGainDefects | PH Gain Defects | 0 | |
PHPar1Defects | PH Parameter1 Defects | 0 |
TestCenter | Test Center | ETH | |
TestDate | Test Date | 2015-12-07 | |
TestTime | Test Time | 10:25 | |
TestDuration | Duration | 1:22:55 | |
TempC | Temparature | -20 | °C |
TBM1 | TBM1 | ok, 0xf4 0xed | |
TBM2 | TBM2 | ok, 0x00 0xed | |
PxarVersion | pXar | prod-12 | |
DTB_FW | DTB FW | 4.5 | |
ModuleIa | Module Ia | 388.3 | mA |
Noise | Noise | 127.35 | e |
NoiseROCs | Noise grades | 16/0/0 | |
VcalThrWidth | Vcal Thr. Width | 49.06 | e |
VcalThrWidthROCs | Vcal Thr. W. grades | 16/0/0 | |
RelGainWidth | Rel. Gain Width | 0.04 | % |
RelGainWidthROCs | Rel. Gain W. grades | 16/0/0 | |
PedestalSpread | Pedestal Spread | 1088.47 | e |
PedestalSpreadROCs | Ped. Spread grades | 16/0/0 | |
Parameter1 | Parameter1 | 0.73 | |
Parameter1ROCs | Par1 grades | 16/0/0 |
Duration | Duration | 1:22:55 | |
MinCurrent | min. Current | 0.376 | A |
MaxCurrent | max. Current | 0.544 | A |
Duration | Duration | 1:22:55 | |
MinCurrent | min. Current | 0.071 | A |
MaxCurrent | max. Current | 0.392 | A |
ModuleIa | Module Ia | 388.3 | mA |
IanaLossProblems | Iana problems | No | |
Mean | mean | 19.55 | |
Min | min | 18.50 | |
Max | max | 20.10 | |
NROCsNotProgrammable | ROCs not programmable | 0 |
Temperature | Temp. while test | -20.00 +/- 0.02 | °C |
Duration | Duration of test | 1:24:34 |
ROC | Grade | Total | Dead | Mask | Bumps | Trim(Bits) | Address | Noise | Thresh | Gain | Ped | Par1 | Mean noise | Thr [e-] | Thr width | Rel gain width | Ped spread |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Chip 0 |
A
|
1
|
0
|
0
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
123.51
|
1749 |
46
|
0.033
|
1106
|
Chip 1 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
133.78
|
1748 |
47
|
0.040
|
1072
|
Chip 2 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
102.97
|
1749 |
44
|
0.037
|
1262
|
Chip 3 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
133.09
|
1749 |
48
|
0.034
|
1161
|
Chip 4 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
134.81
|
1745 |
68
|
0.040
|
1268
|
Chip 5 |
A
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
2
|
0
|
0
|
0
|
149.62
|
1750 |
52
|
0.037
|
1230
|
Chip 6 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
118.18
|
1750 |
48
|
0.032
|
998
|
Chip 7 |
A
|
4
|
0
|
0
|
4
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
126.18
|
1751 |
50
|
0.037
|
1022
|
Chip 8 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
136.07
|
1748 |
48
|
0.034
|
1002
|
Chip 9 |
A
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
2
|
0
|
0
|
0
|
130.78
|
1748 |
48
|
0.045
|
1110
|
Chip 10 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
116.55
|
1750 |
46
|
0.039
|
872
|
Chip 11 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
119.70
|
1748 |
49
|
0.035
|
1004
|
Chip 12 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
137.62
|
1748 |
48
|
0.042
|
1144
|
Chip 13 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
123.35
|
1748 |
48
|
0.039
|
1102
|
Chip 14 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
127.92
|
1750 |
48
|
0.036
|
1046
|
Chip 15 |
A
|
4
|
0
|
0
|
3
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
123.51
|
1750 |
47
|
0.040
|
1017
|
ModifiedGrading | Modified Grading | True | |
GradingParameters_leakageCurrentRatioB | leakageCurrentRatioB | 20 => -111 |
nTBMs | n | 1 | |
TBMType | Type | tbm09c | |
Core0a_basea | Core 0a base a | 0xed | |
Core0a_basee | Core 0a base e | 0xf4 | |
Core0b_basea | Core 0b base a | 0xed | |
Core0b_basee | Core 0b base e | 0x00 | |
RocDelay_Ch0 | Roc Delay Ch0 | 5 | |
RocDelay_Ch1 | Roc Delay Ch1 | 5 | |
RocDelay_Ch2 | Roc Delay Ch2 | 5 | |
RocDelay_Ch3 | Roc Delay Ch3 | 5 | |
Phase400 | Phase 400 | 5 | |
Phase160 | Phase 160 | 7 |
nCriticals | # Criticals | 0 | |
nErrors | # Errors | 0 | |
nWarnings | # Warnings | 0 | |
channel_0_count | Channel 0 | 0 | |
channel_1_count | Channel 1 | 0 | |
channel_2_count | Channel 2 | 0 | |
channel_3_count | Channel 3 | 0 |
