Test Date: 2015-12-08 13:49
Analysis date: 2016-05-26 06:41
Analysis date: 2016-05-26 06:41
M2121 XRayHRQualification
Summary
| Module | Module | M2121 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 4 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.28 | % |
| Noise | Mean Noise | 166 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 99.02 | 0.46 | 70.7 | 0 | 23.8 | 0/0 | 0 | 1925 | 162 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.86 | 99.29 | 0.47 | 75.2 | 0 | 25.1 | 0/0 | 0 | 1948 | 177 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.33 | 0.31 | 67.3 | 0 | 22.2 | 0/0 | 0 | 1931 | 155 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.33 | 0.41 | 133.3 | 0 | 45.7 | 0/0 | 0 | 2104 | 176 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.87 | 99.33 | 0.42 | 136.8 | 1 | 47.3 | 0/0 | 0 | 2098 | 170 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.89 | 99.35 | 0.78 | 162.9 | 0 | 57.3 | 0/0 | 0 | 2154 | 168 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.34 | 0.63 | 147.6 | 0 | 51.5 | 0/0 | 0 | 2103 | 158 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.32 | 0.99 | 170.8 | 0 | 59.8 | 0/0 | 0 | 2188 | 164 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.86 | 99.32 | 0.98 | 152.8 | 0 | 53.0 | 0/0 | 0 | 2130 | 163 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.85 | 99.13 | 0.82 | 144.3 | 0 | 49.8 | 0/0 | 0 | 2117 | 173 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.36 | 0.66 | 142.5 | 0 | 49.7 | 0/0 | 0 | 2100 | 162 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.33 | 0.5 | 126.3 | 0 | 43.1 | 0/0 | 0 | 2063 | 168 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.85 | 99.31 | 0.9 | 111.3 | 0 | 37.7 | 0/0 | 0 | 2016 | 175 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.84 | 99.27 | 1.46 | 62.2 | 0 | 20.4 | 0/0 | 0 | 1903 | 159 | 1 |
|
Chip 14
|
A
|
0 | 0 | 99.87 | 99.31 | 0.43 | 65.9 | 0 | 21.6 | 0/0 | 0 | 1919 | 168 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.87 | 99.22 | 0.32 | 63.1 | 0 | 21.0 | 0/0 | 0 | 1920 | 161 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-12-08 | |
| TestTime | Test Time | 13:49 | |
| TestDuration | Duration | 1:40:25 | |
| pXar | pXar version | prod-12 | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 2 | |
| nErrors | # Errors | 53 | |
| nWarnings | # Warnings | 2 | |
| channel_0_count | Channel 0 | 4 | |
| channel_1_count | Channel 1 | 3 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_missingevents_count | Missing Event criticals | 1 | |
| message_tokenchain_count | Token Chain Length | 3 | |
| message_datasize_count | Data size criticals | 1 | |
| message_readback_count | Readback start marker | 2 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
