Test Date: 2015-11-23 13:32
Analysis date: 2016-05-26 06:35
Analysis date: 2016-05-26 06:35
M2120 XRayHRQualification
Summary
| Module | Module | M2120 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 10 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 6 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.29 | % |
| Noise | Mean Noise | 169 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
4 | 0 | 99.86 | 99.26 | 0.57 | 97.8 | 0 | 33.2 | 0/0 | 0 | 1833 | 169 | 4 |
|
Chip 1
|
A
|
1 | 0 | 99.85 | 99.28 | 1.31 | 101.2 | 0 | 34.3 | 0/0 | 0 | 1987 | 169 | 1 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 99.03 | 0.82 | 104.3 | 0 | 34.8 | 0/0 | 0 | 1995 | 177 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.29 | 0.46 | 156.8 | 0 | 54.9 | 0/0 | 0 | 2150 | 158 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.88 | 99.41 | 0.5 | 153.3 | 0 | 52.4 | 0/0 | 0 | 2131 | 158 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.86 | 99.40 | 0.6 | 218.1 | 0 | 76.9 | 0/0 | 0 | 2280 | 176 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.37 | 0.61 | 200.8 | 0 | 70.0 | 0/0 | 0 | 2218 | 162 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.88 | 99.41 | 0.25 | 230.8 | 0 | 80.1 | 0/0 | 0 | 2250 | 171 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.90 | 99.41 | 0.35 | 215.8 | 0 | 75.8 | 0/0 | 0 | 2247 | 177 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.33 | 0.63 | 193.6 | 0 | 68.0 | 0/0 | 0 | 2222 | 166 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.33 | 0.65 | 199.2 | 0 | 70.8 | 0/0 | 0 | 2235 | 154 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.35 | 0.52 | 191.4 | 0 | 66.8 | 0/0 | 0 | 2234 | 172 | 0 |
|
Chip 12
|
A
|
2 | 0 | 99.89 | 99.24 | 0.48 | 162.7 | 1 | 56.8 | 0/0 | 0 | 2074 | 177 | 1 |
|
Chip 13
|
A
|
0 | 0 | 99.87 | 99.25 | 0.45 | 96.1 | 0 | 32.2 | 0/0 | 0 | 1966 | 181 | 0 |
|
Chip 14
|
A
|
2 | 0 | 99.88 | 99.28 | 1.23 | 99.6 | 0 | 33.6 | 0/0 | 0 | 1985 | 170 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.83 | 99.02 | 1.38 | 98.4 | 0 | 33.4 | 0/0 | 0 | 1991 | 174 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-11-23 | |
| TestTime | Test Time | 13:32 | |
| TestDuration | Duration | 1:33:19 | |
| pXar | pXar version | v2.6.0+26~g89693ff | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 43 | |
| nWarnings | # Warnings | 2 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 4 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 1 | |
| message_tokenchain_count | Token Chain Length | 3 | |
| message_readback_count | Readback start marker | 2 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
