Test Date: 2015-11-23 13:32
Analysis date: 2016-05-26 06:26
Analysis date: 2016-05-26 06:26
M2119 XRayHRQualification
Summary
| Module | Module | M2119 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 27 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 19 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.25 | % |
| Noise | Mean Noise | 174 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.85 | 99.03 | 0.68 | 73.0 | 0 | 24.7 | 0/0 | 0 | 1949 | 177 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.87 | 99.32 | 0.55 | 86.9 | 0 | 29.3 | 0/0 | 0 | 1899 | 194 | 1 |
|
Chip 2
|
A
|
2 | 0 | 99.86 | 99.35 | 0.48 | 67.5 | 0 | 22.2 | 0/0 | 0 | 1861 | 163 | 2 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.33 | 0.68 | 122.3 | 0 | 42.6 | 0/0 | 0 | 2075 | 171 | 0 |
|
Chip 4
|
A
|
2 | 0 | 99.87 | 99.34 | 0.65 | 144.5 | 0 | 50.5 | 0/0 | 0 | 2093 | 177 | 1 |
|
Chip 5
|
A
|
0 | 0 | 99.90 | 99.36 | 0.38 | 167.8 | 0 | 59.5 | 0/0 | 0 | 2154 | 174 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.89 | 99.32 | 0.64 | 154.9 | 0 | 54.4 | 0/0 | 0 | 2111 | 168 | 1 |
|
Chip 7
|
A
|
2 | 0 | 99.89 | 99.35 | 0.42 | 161.3 | 0 | 56.6 | 0/0 | 0 | 2075 | 164 | 2 |
|
Chip 8
|
A
|
2 | 0 | 99.86 | 99.01 | 0.76 | 152.8 | 0 | 53.8 | 0/0 | 0 | 2106 | 169 | 1 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.33 | 0.74 | 147.4 | 0 | 51.7 | 0/0 | 0 | 2121 | 174 | 0 |
|
Chip 10
|
A
|
2 | 0 | 99.87 | 99.29 | 0.64 | 153.0 | 0 | 54.3 | 0/0 | 0 | 2164 | 171 | 0 |
|
Chip 11
|
A
|
10 | 0 | 99.89 | 99.37 | 0.41 | 124.5 | 0 | 43.3 | 0/0 | 0 | 1841 | 169 | 7 |
|
Chip 12
|
A
|
1 | 0 | 99.86 | 99.06 | 0.64 | 120.9 | 0 | 41.5 | 0/0 | 0 | 2001 | 190 | 1 |
|
Chip 13
|
A
|
0 | 0 | 99.87 | 99.32 | 0.47 | 62.3 | 0 | 20.5 | 0/0 | 0 | 1935 | 167 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 98.96 | 1.14 | 68.2 | 0 | 22.7 | 0/0 | 0 | 1946 | 171 | 0 |
|
Chip 15
|
A
|
4 | 0 | 99.85 | 99.26 | 0.67 | 70.0 | 0 | 23.5 | 0/0 | 0 | 1793 | 186 | 3 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-11-23 | |
| TestTime | Test Time | 13:32 | |
| TestDuration | Duration | 1:33:19 | |
| pXar | pXar version | v2.6.0+26~g89693ff | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 9 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 1 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_notokenpass_count | has NoTokenPass | 1 |
