Module | Module | M2117 | |
Grade | Grade | C | |
ElectricalGrade | Electrical Grade | C | |
IVGrade | IV Grade | A | |
ManualGrade | Manual Grade | None | |
PixelDefects | Pixel Defects - A/B/C | 50 - 16/0/0 | |
DeadPixels | Dead Pixels | 1 | |
AddressProblems | Address Problems | 0 | |
ThresholdDefects | Threshold Defects | 48 | |
MaskDefects | Mask Defects | 0 | |
DeadBumps | Dead Bumps | 1 | |
NoisyPixels | Noise Defects | 0 | |
TrimProblems | Trim Problems | 0 | |
PHGainDefects | PH Gain Defects | 1 | |
PHPar1Defects | PH Parameter1 Defects | 0 | |
SpecialDefects | Defects | HDI |
TestCenter | Test Center | ETH | |
TestDate | Test Date | 2016-01-26 | |
TestTime | Test Time | 16:37 | |
TestDuration | Duration | 1:22:29 | |
TempC | Temparature | 17 | °C |
TBM1 | TBM1 | ok, 0x34 0x64 | |
TBM2 | TBM2 | ok, 0x00 0x64 | |
PxarVersion | pXar | prod-12 | |
DTB_FW | DTB FW | 4.5 | |
ModuleIa | Module Ia | 373 | mA |
Noise | Noise | 140.71 | e |
NoiseROCs | Noise grades | 16/0/0 | |
VcalThrWidth | Vcal Thr. Width | 47.84 | e |
VcalThrWidthROCs | Vcal Thr. W. grades | 16/0/0 | |
RelGainWidth | Rel. Gain Width | 0.04 | % |
RelGainWidthROCs | Rel. Gain W. grades | 16/0/0 | |
PedestalSpread | Pedestal Spread | 1265.97 | e |
PedestalSpreadROCs | Ped. Spread grades | 16/0/0 | |
Parameter1 | Parameter1 | 0.70 | |
Parameter1ROCs | Par1 grades | 16/0/0 | |
CurrentAtVoltage150V | I(150 V) | 0.79 | μA |
CurrentVariation | I(150 V) / I(100 V) | 1.42 |
Duration | Duration | 1:22:29 | |
MinCurrent | min. Current | 0.371 | A |
MaxCurrent | max. Current | 0.627 | A |
Duration | Duration | 1:22:29 | |
MinCurrent | min. Current | 0.072 | A |
MaxCurrent | max. Current | 0.392 | A |
ModuleIa | Module Ia | 373 | mA |
IanaLossProblems | Iana problems | Yes | |
Mean | mean | 13.11 | |
Min | min | 9.60 | |
Max | max | 16.10 | |
NROCsNotProgrammable | ROCs not programmable | 0 |
Temperature | Temp. while test | 17.00 +/- 0.05 | °C |
Duration | Duration of test | 1:22:33 |
ROC | Grade | Total | Dead | Mask | Bumps | Trim(Bits) | Address | Noise | Thresh | Gain | Ped | Par1 | Mean noise | Thr [e-] | Thr width | Rel gain width | Ped spread |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Chip 0 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
156.28
|
1750 |
48
|
0.029
|
1162
|
Chip 1 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
140.51
|
1746 |
52
|
0.036
|
1242
|
Chip 2 |
A
|
6
|
0
|
0
|
0
|
0
|
0
|
0
|
6
|
0
|
0
|
0
|
137.83
|
1750 |
48
|
0.049
|
1192
|
Chip 3 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
137.55
|
1749 |
42
|
0.031
|
1256
|
Chip 4 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
151.84
|
1752 |
50
|
0.031
|
1356
|
Chip 5 |
A
|
22
|
0
|
0
|
0
|
0
|
0
|
0
|
22
|
0
|
0
|
0
|
146.67
|
1748 |
56
|
0.056
|
1698
|
Chip 6 |
A
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
2
|
0
|
0
|
0
|
162.26
|
1750 |
54
|
0.039
|
1236
|
Chip 7 |
A
|
5
|
0
|
0
|
1
|
0
|
0
|
0
|
4
|
0
|
0
|
0
|
133.52
|
1750 |
46
|
0.041
|
1206
|
Chip 8 |
A
|
6
|
0
|
0
|
0
|
0
|
0
|
0
|
6
|
0
|
0
|
0
|
135.36
|
1748 |
50
|
0.043
|
1294
|
Chip 9 |
A
|
3
|
0
|
0
|
0
|
0
|
0
|
0
|
3
|
0
|
0
|
0
|
149.16
|
1748 |
50
|
0.040
|
1201
|
Chip 10 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
141.03
|
1750 |
45
|
0.043
|
1192
|
Chip 11 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
135.03
|
1749 |
44
|
0.042
|
1156
|
Chip 12 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
135.09
|
1749 |
48
|
0.035
|
1132
|
Chip 13 |
A
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
2
|
0
|
0
|
0
|
124.92
|
1752 |
46
|
0.040
|
1370
|
Chip 14 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
134.38
|
1749 |
44
|
0.032
|
1238
|
Chip 15 |
A
|
1
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
129.91
|
1750 |
43
|
0.033
|
1322
|
ModifiedGrading | Modified Grading | True | |
GradingParameters_leakageCurrentRatioB | leakageCurrentRatioB | 20 => -111 |
nTBMs | n | 1 | |
TBMType | Type | tbm09c | |
Core0a_basea | Core 0a base a | 0x64 | |
Core0a_basee | Core 0a base e | 0x34 | |
Core0b_basea | Core 0b base a | 0x64 | |
Core0b_basee | Core 0b base e | 0x00 | |
RocDelay_Ch0 | Roc Delay Ch0 | 4 | |
RocDelay_Ch1 | Roc Delay Ch1 | 4 | |
RocDelay_Ch2 | Roc Delay Ch2 | 4 | |
RocDelay_Ch3 | Roc Delay Ch3 | 4 | |
Phase400 | Phase 400 | 5 | |
Phase160 | Phase 160 | 1 |
nCriticals | # Criticals | 0 | |
nErrors | # Errors | 46 | |
nWarnings | # Warnings | 0 | |
channel_0_count | Channel 0 | 22 | |
channel_1_count | Channel 1 | 24 | |
channel_2_count | Channel 2 | 0 | |
channel_3_count | Channel 3 | 0 | |
message_eventid_count | Event ID mismatch | 16 | |
message_tokenchain_count | Token Chain Length | 18 | |
message_notokenpass_count | has NoTokenPass | 12 |
