Test Date: 2015-09-17 11:03
Analysis date: 2016-05-26 06:12
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
46.698625 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
46.698625 |
|
| medianSlope |
median Slope |
46.4295 |
|
| minSlope |
min Slope |
43.978 |
|
| maxSlope |
max Slope |
50.25 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-59.36375 |
|
| medianOffset |
median Offset |
-39.0705 |
|
| minOffset |
min Offset |
-214.329 |
|
| maxOffset |
max Offset |
56.573 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
4.52266666667 |
|
| medianchi2 |
median chi2 |
0.751 |
|
| minchi2 |
min chi2 |
0.012 |
|
| maxchi2 |
max chi2 |
38.366 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
45.0 e- / Vcal
|
0.2 e- / Vcal
|
-6.1 e-
|
20.9 e-
|
|
1
|
46.1 e- / Vcal
|
0.1 e- / Vcal
|
-181.5 e-
|
17.9 e-
|
|
2
|
46.3 e- / Vcal
|
0.2 e- / Vcal
|
-12.0 e-
|
21.1 e-
|
|
3
|
47.8 e- / Vcal
|
0.1 e- / Vcal
|
6.7 e-
|
5.7 e-
|
|
4
|
46.2 e- / Vcal
|
0.1 e- / Vcal
|
35.7 e-
|
15.9 e-
|
|
5
|
47.7 e- / Vcal
|
0.2 e- / Vcal
|
56.6 e-
|
18.3 e-
|
|
6
|
45.9 e- / Vcal
|
0.1 e- / Vcal
|
-140.8 e-
|
16.3 e-
|
|
7
|
44.0 e- / Vcal
|
0.1 e- / Vcal
|
-81.1 e-
|
6.6 e-
|
|
8
|
47.0 e- / Vcal
|
0.1 e- / Vcal
|
-57.2 e-
|
6.3 e-
|
|
9
|
47.6 e- / Vcal
|
0.1 e- / Vcal
|
-110.5 e-
|
17.3 e-
|
|
10
|
46.6 e- / Vcal
|
0.1 e- / Vcal
|
-82.9 e-
|
6.2 e-
|
|
11
|
48.3 e- / Vcal
|
0.1 e- / Vcal
|
-140.8 e-
|
16.6 e-
|
|
12
|
50.2 e- / Vcal
|
0.1 e- / Vcal
|
-214.3 e-
|
17.5 e-
|
|
13
|
46.3 e- / Vcal
|
0.1 e- / Vcal
|
13.3 e-
|
7.7 e-
|
|
14
|
45.5 e- / Vcal
|
0.1 e- / Vcal
|
-20.9 e-
|
19.0 e-
|
|
15
|
46.8 e- / Vcal
|
0.1 e- / Vcal
|
-13.7 e-
|
7.7 e-
|
|
Average
|
46.7 e- / Vcal
|
|
-59.4 e-
|
|
|
Median
|
91.0 e- / Vcal
|
|
-138.4 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
