Test Date: 2015-09-04 17:08
Analysis date: 2016-05-26 04:27
Analysis date: 2016-05-26 04:27
M2102 XRayHRQualification
Summary
| Module | Module | M2102 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 45 | |
| BumpBondingDefects | Bump Bonding Defects | 41 | |
| NoisyPixels | Noisy Pixels | 4 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.26 | % |
| Noise | Mean Noise | 160 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
39 | 0 | 99.86 | 98.90 | 0.39 | 63.3 | 37 | 21.2 | 0/0 | 0 | 1843 | 159 | 2 |
|
Chip 1
|
A
|
0 | 0 | 99.88 | 99.34 | 0.4 | 66.7 | 0 | 22.1 | 0/0 | 0 | 1924 | 157 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.04 | 0.46 | 55.7 | 0 | 18.1 | 0/0 | 0 | 1900 | 151 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.84 | 99.35 | 0.78 | 103.8 | 0 | 35.5 | 0/0 | 0 | 2024 | 156 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.88 | 99.33 | 0.7 | 117.9 | 0 | 40.7 | 0/0 | 0 | 2067 | 166 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.36 | 0.7 | 155.2 | 0 | 54.6 | 0/0 | 0 | 2154 | 162 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.89 | 99.35 | 0.7 | 132.9 | 0 | 46.3 | 0/0 | 0 | 2122 | 153 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.88 | 99.32 | 0.51 | 150.0 | 0 | 52.1 | 0/0 | 0 | 2131 | 158 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.89 | 99.29 | 0.75 | 160.6 | 0 | 56.0 | 0/0 | 0 | 2169 | 165 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.89 | 99.34 | 0.51 | 148.1 | 0 | 51.8 | 0/0 | 0 | 2122 | 160 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.89 | 99.38 | 0.62 | 166.0 | 0 | 58.7 | 0/0 | 0 | 2177 | 160 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.89 | 99.36 | 0.47 | 141.0 | 0 | 49.0 | 0/0 | 0 | 2138 | 165 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.37 | 0.51 | 123.5 | 0 | 42.8 | 0/0 | 0 | 2076 | 163 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.86 | 99.30 | 0.53 | 67.2 | 0 | 22.3 | 0/0 | 0 | 1936 | 149 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.86 | 99.09 | 0.55 | 75.5 | 0 | 25.4 | 0/0 | 0 | 1964 | 161 | 0 |
|
Chip 15
|
A
|
6 | 0 | 99.86 | 99.06 | 0.42 | 73.2 | 4 | 24.7 | 0/0 | 0 | 1879 | 168 | 2 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-09-04 | |
| TestTime | Test Time | 17:08 | |
| TestDuration | Duration | 1:18:56 | |
| pXar | pXar version | prod-10 | |
| DTB_FW | DTB FW | 4.4 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 2 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 2 | |
| message_readback_count | Readback start marker | 2 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
