Test Date: 2015-08-31 11:49
Analysis date: 2016-05-26 03:33
Analysis date: 2016-05-26 03:33
M2091 XRayHRQualification
Summary
| Module | Module | M2091 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 13 | |
| BumpBondingDefects | Bump Bonding Defects | 13 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.30 | % |
| Noise | Mean Noise | 168 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.87 | 99.17 | 0.79 | 86.5 | 1 | 29.4 | 0/0 | 0 | 1979 | 172 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.87 | 99.34 | 0.69 | 100.9 | 1 | 34.0 | 0/0 | 0 | 2018 | 184 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.80 | 99.23 | 2.3 | 90.4 | 0 | 30.3 | 0/0 | 0 | 2013 | 171 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.34 | 0.61 | 158.2 | 0 | 55.6 | 0/0 | 0 | 2182 | 165 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.88 | 99.29 | 0.61 | 175.7 | 0 | 61.3 | 0/0 | 0 | 2208 | 180 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.34 | 0.67 | 195.3 | 0 | 69.6 | 0/0 | 0 | 2238 | 161 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.36 | 0.56 | 202.1 | 0 | 70.8 | 0/0 | 0 | 2272 | 170 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.85 | 99.25 | 0.91 | 218.9 | 0 | 76.3 | 0/0 | 0 | 2269 | 173 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.86 | 99.35 | 0.55 | 204.3 | 0 | 72.0 | 0/0 | 0 | 2270 | 160 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.35 | 0.53 | 186.1 | 0 | 65.5 | 0/0 | 0 | 2203 | 159 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.31 | 0.81 | 201.5 | 0 | 71.4 | 0/0 | 0 | 2243 | 166 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.33 | 0.53 | 165.3 | 0 | 57.7 | 0/0 | 0 | 2176 | 161 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.28 | 0.35 | 147.1 | 0 | 51.3 | 0/0 | 0 | 2136 | 165 | 0 |
|
Chip 13
|
A
|
9 | 0 | 99.86 | 99.30 | 0.48 | 87.8 | 9 | 29.2 | 0/0 | 0 | 2017 | 159 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.86 | 99.30 | 0.67 | 95.3 | 0 | 32.2 | 0/0 | 0 | 2021 | 169 | 0 |
|
Chip 15
|
A
|
2 | 0 | 99.86 | 99.31 | 1.2 | 94.9 | 2 | 32.4 | 0/0 | 0 | 2000 | 181 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-31 | |
| TestTime | Test Time | 11:49 | |
| TestDuration | Duration | 1:31:25 | |
| pXar | pXar version | v2.5+57~g44d0777 | |
| DTB_FW | DTB FW | 4.4 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
