Test Date: 2015-08-24 17:49
Analysis date: 2016-05-26 02:42
Analysis date: 2016-05-26 02:42
M2083 XRayHRQualification
Summary
| Module | Module | M2083 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 45 | |
| BumpBondingDefects | Bump Bonding Defects | 40 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.82/99.26 | % |
| Noise | Mean Noise | 161 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
16 | 0 | 99.88 | 99.21 | 0.83 | 72.1 | 13 | 23.9 | 0/0 | 0 | 1955 | 176 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.86 | 99.23 | 0.36 | 74.8 | 0 | 24.6 | 0/0 | 0 | 1972 | 178 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.78 | 99.26 | 11.9 | 62.9 | 0 | 20.6 | 0/0 | 0 | 1946 | 164 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.13 | 99.13 | 43.44 | 111.6 | 0 | 38.3 | 0/0 | 0 | 2071 | 158 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.90 | 99.33 | 0.8 | 110.3 | 0 | 37.9 | 0/0 | 0 | 2056 | 151 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.89 | 99.33 | 0.54 | 132.7 | 0 | 46.5 | 0/0 | 0 | 2137 | 153 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.29 | 0.47 | 144.3 | 0 | 50.3 | 0/0 | 0 | 2139 | 160 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.86 | 99.28 | 0.75 | 139.3 | 0 | 48.2 | 0/0 | 0 | 2119 | 156 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.30 | 0.39 | 140.1 | 0 | 48.7 | 0/0 | 0 | 2129 | 155 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.87 | 99.35 | 0.96 | 147.4 | 1 | 51.5 | 0/0 | 0 | 2130 | 156 | 0 |
|
Chip 10
|
A
|
2 | 0 | 99.88 | 99.35 | 0.62 | 154.4 | 2 | 54.8 | 0/0 | 0 | 2182 | 155 | 0 |
|
Chip 11
|
A
|
4 | 0 | 99.86 | 99.26 | 0.97 | 134.8 | 4 | 46.7 | 0/0 | 0 | 2145 | 162 | 0 |
|
Chip 12
|
A
|
6 | 0 | 99.86 | 99.32 | 0.58 | 132.2 | 6 | 45.6 | 0/0 | 0 | 2134 | 167 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.87 | 99.29 | 0.28 | 65.2 | 0 | 21.5 | 0/0 | 0 | 1965 | 151 | 0 |
|
Chip 14
|
A
|
2 | 0 | 99.85 | 98.99 | 0.71 | 75.2 | 2 | 25.0 | 0/0 | 0 | 1982 | 166 | 0 |
|
Chip 15
|
A
|
14 | 0 | 99.88 | 99.26 | 0.31 | 71.0 | 12 | 23.7 | 0/0 | 0 | 1926 | 164 | 1 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-24 | |
| TestTime | Test Time | 17:49 | |
| TestDuration | Duration | 0:29:22 | |
| pXar | pXar version | prod-01+86~g1838649 | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 12 | |
| nWarnings | # Warnings | 12 | |
| channel_0_count | Channel 0 | 12 | |
| channel_1_count | Channel 1 | 7 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 5 | |
| message_eventid_count | Event ID mismatch | 3 | |
| message_tokenchain_count | Token Chain Length | 9 | |
| message_readback_count | Readback start marker | 12 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
