Test Date: 2015-08-24 08:08
Analysis date: 2016-05-26 02:17
Analysis date: 2016-05-26 02:17
M2079 XRayHRQualification
Summary
| Module | Module | M2079 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 4 | |
| BumpBondingDefects | Bump Bonding Defects | 2 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.25 | % |
| Noise | Mean Noise | 168 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.88 | 99.28 | 0.35 | 68.9 | 0 | 23.1 | 0/0 | 0 | 1931 | 167 | 0 |
|
Chip 1
|
A
|
2 | 0 | 99.86 | 99.23 | 0.47 | 75.5 | 1 | 25.2 | 0/0 | 0 | 1935 | 176 | 1 |
|
Chip 2
|
A
|
0 | 0 | 99.88 | 99.35 | 0.44 | 65.6 | 0 | 21.7 | 0/0 | 0 | 1933 | 166 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.03 | 0.88 | 122.7 | 0 | 42.3 | 0/0 | 0 | 2082 | 176 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.86 | 99.36 | 0.39 | 123.4 | 0 | 42.6 | 0/0 | 0 | 2094 | 164 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.90 | 99.36 | 0.3 | 134.1 | 0 | 46.9 | 0/0 | 0 | 2115 | 157 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.30 | 0.39 | 157.5 | 0 | 54.4 | 0/0 | 0 | 2182 | 180 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.85 | 99.24 | 0.95 | 143.3 | 0 | 49.7 | 0/0 | 0 | 2146 | 165 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.89 | 99.34 | 0.49 | 156.1 | 0 | 54.3 | 0/0 | 0 | 2163 | 171 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.26 | 0.89 | 149.7 | 0 | 52.5 | 0/0 | 0 | 2135 | 159 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.88 | 99.33 | 0.52 | 156.8 | 1 | 55.2 | 0/0 | 0 | 2155 | 163 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.89 | 99.34 | 0.62 | 130.2 | 0 | 45.0 | 0/0 | 0 | 2096 | 164 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.22 | 0.6 | 127.2 | 0 | 43.6 | 0/0 | 0 | 2078 | 174 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.86 | 99.24 | 0.36 | 72.6 | 0 | 24.1 | 0/0 | 0 | 1974 | 173 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 98.94 | 0.63 | 74.0 | 0 | 24.5 | 0/0 | 0 | 1969 | 164 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.87 | 99.20 | 0.82 | 75.6 | 0 | 25.4 | 0/0 | 0 | 1956 | 172 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-24 | |
| TestTime | Test Time | 08:08 | |
| TestDuration | Duration | 1:29:5 | |
| pXar | pXar version | prod-01+80~g16e673b | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 7 | |
| nWarnings | # Warnings | 2 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 9 | |
| message_eventid_count | Event ID mismatch | 4 | |
| message_tokenchain_count | Token Chain Length | 3 | |
| message_readback_count | Readback start marker | 2 |
