Test Date: 2015-09-11 16:58
Analysis date: 2016-05-26 01:59
X-ray Calibration - Spectrum
Slope |
avrg Slope |
45.06675 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
avrgSlope |
avrg Slope |
45.06675 |
|
medianSlope |
median Slope |
44.7995 |
|
minSlope |
min Slope |
42.487 |
|
maxSlope |
max Slope |
47.968 |
|
Offset of Spectrum Vcal Calibration
avrgOffset |
avrg Offset |
10.2885 |
|
medianOffset |
median Offset |
-20.43 |
|
minOffset |
min Offset |
-145.345 |
|
maxOffset |
max Offset |
424.535 |
|
Chi2 of Spectrum Vcal Calibration
avrgchi2 |
avrg chi2 |
4.917875 |
|
medianchi2 |
median chi2 |
1.399 |
|
minchi2 |
min chi2 |
0.005 |
|
maxchi2 |
max chi2 |
36.864 |
|
Vcal Calibration Module - Spectrum
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
0
|
44.8 e- / Vcal
|
0.3 e- / Vcal
|
424.5 e-
|
32.2 e-
|
1
|
44.1 e- / Vcal
|
0.1 e- / Vcal
|
-48.2 e-
|
6.7 e-
|
2
|
47.9 e- / Vcal
|
0.2 e- / Vcal
|
121.8 e-
|
23.7 e-
|
3
|
44.8 e- / Vcal
|
0.1 e- / Vcal
|
-80.4 e-
|
6.8 e-
|
4
|
48.0 e- / Vcal
|
0.1 e- / Vcal
|
-15.4 e-
|
5.5 e-
|
5
|
46.5 e- / Vcal
|
0.1 e- / Vcal
|
-2.8 e-
|
6.3 e-
|
6
|
44.7 e- / Vcal
|
0.1 e- / Vcal
|
-72.0 e-
|
18.2 e-
|
7
|
42.6 e- / Vcal
|
0.1 e- / Vcal
|
-32.4 e-
|
6.2 e-
|
8
|
46.8 e- / Vcal
|
0.1 e- / Vcal
|
-78.8 e-
|
16.5 e-
|
9
|
46.2 e- / Vcal
|
0.1 e- / Vcal
|
74.9 e-
|
6.1 e-
|
10
|
44.1 e- / Vcal
|
0.0 e- / Vcal
|
-145.3 e-
|
5.4 e-
|
11
|
44.8 e- / Vcal
|
0.1 e- / Vcal
|
-25.4 e-
|
6.0 e-
|
12
|
45.1 e- / Vcal
|
0.1 e- / Vcal
|
-61.1 e-
|
16.4 e-
|
13
|
42.5 e- / Vcal
|
0.2 e- / Vcal
|
-1.7 e-
|
20.7 e-
|
14
|
43.6 e- / Vcal
|
0.1 e- / Vcal
|
90.5 e-
|
7.1 e-
|
15
|
44.6 e- / Vcal
|
0.1 e- / Vcal
|
16.4 e-
|
7.3 e-
|
Average
|
45.1 e- / Vcal
|
|
10.3 e-
|
|
Median
|
89.3 e- / Vcal
|
|
-111.3 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
