Test Date: 2015-08-21 11:04
Analysis date: 2016-05-26 01:49
Analysis date: 2016-05-26 01:49
M2075 XRayHRQualification
Summary
| Module | Module | M2075 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 17 | |
| BumpBondingDefects | Bump Bonding Defects | 15 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.22 | % |
| Noise | Mean Noise | 162 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
3 | 0 | 99.86 | 99.16 | 0.34 | 64.0 | 3 | 21.3 | 0/0 | 0 | 1931 | 167 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.87 | 98.98 | 0.36 | 60.4 | 1 | 19.6 | 0/0 | 0 | 1935 | 154 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.34 | 0.38 | 56.8 | 0 | 18.4 | 0/0 | 0 | 1921 | 153 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.29 | 0.58 | 118.9 | 0 | 40.6 | 0/0 | 0 | 2061 | 162 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.83 | 99.05 | 0.81 | 114.2 | 0 | 38.9 | 0/0 | 0 | 2060 | 160 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.31 | 0.95 | 138.7 | 0 | 48.3 | 0/0 | 0 | 2126 | 163 | 0 |
|
Chip 6
|
A
|
2 | 0 | 99.88 | 99.32 | 0.81 | 127.3 | 2 | 43.9 | 0/0 | 0 | 2093 | 156 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.89 | 99.34 | 0.63 | 113.3 | 0 | 38.2 | 0/0 | 0 | 2043 | 150 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.32 | 0.63 | 138.3 | 0 | 47.3 | 0/0 | 0 | 2110 | 159 | 0 |
|
Chip 9
|
A
|
2 | 0 | 99.88 | 99.36 | 0.46 | 124.4 | 2 | 42.4 | 0/0 | 0 | 2075 | 156 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.90 | 99.36 | 0.48 | 147.0 | 1 | 51.4 | 0/0 | 0 | 2154 | 166 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.33 | 0.78 | 123.9 | 0 | 42.6 | 0/0 | 0 | 2083 | 162 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.90 | 99.35 | 0.67 | 126.3 | 0 | 43.1 | 0/0 | 0 | 2114 | 167 | 0 |
|
Chip 13
|
A
|
5 | 0 | 99.85 | 99.05 | 0.46 | 68.1 | 3 | 22.5 | 0/0 | 0 | 1924 | 162 | 2 |
|
Chip 14
|
A
|
2 | 0 | 99.83 | 99.01 | 0.86 | 79.2 | 2 | 26.2 | 0/0 | 0 | 1960 | 185 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.86 | 98.97 | 0.5 | 73.1 | 1 | 24.4 | 0/0 | 0 | 1960 | 176 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-21 | |
| TestTime | Test Time | 11:04 | |
| TestDuration | Duration | 1:26:19 | |
| pXar | pXar version | v2.2.5+88~g694c14c | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 5 | |
| nWarnings | # Warnings | 2 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 7 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_tokenchain_count | Token Chain Length | 3 | |
| message_readback_count | Readback start marker | 2 |
