Test Date: 2015-08-13 17:13
Analysis date: 2016-05-26 01:29
Analysis date: 2016-05-26 01:29
M2071 XRayHRQualification
Summary
| Module | Module | M2071 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 34 | |
| BumpBondingDefects | Bump Bonding Defects | 32 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.30 | % |
| Noise | Mean Noise | 157 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
8 | 0 | 99.87 | 99.34 | 0.5 | 81.5 | 8 | 27.4 | 0/0 | 0 | 1963 | 157 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.85 | 99.05 | 0.82 | 86.4 | 1 | 28.7 | 0/0 | 0 | 1994 | 153 | 0 |
|
Chip 2
|
A
|
4 | 0 | 99.82 | 99.00 | 0.91 | 88.9 | 4 | 29.7 | 0/0 | 0 | 1994 | 170 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.36 | 0.66 | 143.1 | 0 | 49.9 | 0/0 | 0 | 2158 | 159 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.86 | 99.32 | 0.59 | 148.9 | 0 | 51.7 | 0/0 | 0 | 2130 | 155 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.86 | 99.40 | 0.62 | 194.1 | 0 | 69.2 | 0/0 | 0 | 2254 | 152 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.36 | 0.43 | 202.5 | 0 | 71.0 | 0/0 | 0 | 2272 | 152 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.38 | 0.45 | 172.9 | 0 | 60.1 | 0/0 | 0 | 2177 | 148 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.85 | 99.36 | 0.8 | 203.8 | 0 | 71.7 | 0/0 | 0 | 2267 | 155 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.26 | 1.55 | 201.5 | 0 | 70.8 | 0/0 | 0 | 2259 | 153 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.34 | 0.62 | 189.0 | 0 | 66.8 | 0/0 | 0 | 2231 | 155 | 0 |
|
Chip 11
|
A
|
2 | 0 | 99.89 | 99.36 | 0.47 | 158.1 | 2 | 55.3 | 0/0 | 0 | 2161 | 151 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.87 | 99.34 | 0.56 | 148.8 | 1 | 51.6 | 0/0 | 0 | 2158 | 158 | 0 |
|
Chip 13
|
A
|
2 | 0 | 99.84 | 99.33 | 0.46 | 87.3 | 2 | 29.2 | 0/0 | 0 | 2020 | 152 | 0 |
|
Chip 14
|
A
|
4 | 0 | 99.84 | 99.31 | 1.38 | 98.1 | 2 | 33.0 | 0/0 | 0 | 2032 | 170 | 0 |
|
Chip 15
|
A
|
12 | 0 | 99.85 | 99.25 | 0.76 | 93.9 | 12 | 32.1 | 0/0 | 0 | 2040 | 170 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-13 | |
| TestTime | Test Time | 17:13 | |
| TestDuration | Duration | 1:26:51 | |
| pXar | pXar version | v2.2.5+88~g694c14c | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 7 | |
| nWarnings | # Warnings | 2 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 2 | |
| channel_3_count | Channel 3 | 7 | |
| message_eventid_count | Event ID mismatch | 4 | |
| message_tokenchain_count | Token Chain Length | 3 | |
| message_readback_count | Readback start marker | 2 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
