Test Date: 2015-08-13 17:13
Analysis date: 2016-05-26 01:23
Analysis date: 2016-05-26 01:23
M2070 XRayHRQualification
Summary
| Module | Module | M2070 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 2 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.27 | % |
| Noise | Mean Noise | 161 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 99.00 | 0.71 | 86.1 | 0 | 29.0 | 0/0 | 0 | 1990 | 164 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.85 | 99.23 | 0.79 | 94.5 | 0 | 31.6 | 0/0 | 0 | 1989 | 171 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.01 | 0.59 | 82.7 | 0 | 27.3 | 0/0 | 0 | 1973 | 163 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.83 | 99.26 | 1.82 | 155.3 | 0 | 54.3 | 0/0 | 0 | 2158 | 159 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.88 | 99.36 | 0.65 | 152.5 | 1 | 52.6 | 0/0 | 0 | 2147 | 160 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.27 | 0.64 | 179.8 | 0 | 63.6 | 0/0 | 0 | 2207 | 152 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.89 | 99.36 | 0.43 | 184.0 | 0 | 64.3 | 0/0 | 0 | 2238 | 155 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.90 | 99.37 | 0.61 | 195.6 | 0 | 68.8 | 0/0 | 0 | 2251 | 160 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.85 | 99.29 | 0.6 | 195.8 | 0 | 69.0 | 0/0 | 0 | 2231 | 156 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.89 | 99.32 | 0.46 | 197.7 | 0 | 69.2 | 0/0 | 0 | 2255 | 163 | 1 |
|
Chip 10
|
A
|
1 | 0 | 99.88 | 99.39 | 0.51 | 188.9 | 1 | 67.3 | 0/0 | 0 | 2229 | 156 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.34 | 0.66 | 165.0 | 0 | 57.5 | 0/0 | 0 | 2184 | 162 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.89 | 99.33 | 0.66 | 151.4 | 0 | 52.6 | 0/0 | 0 | 2134 | 161 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.87 | 99.24 | 0.48 | 86.5 | 0 | 28.9 | 0/0 | 0 | 2014 | 162 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.87 | 99.27 | 0.84 | 92.7 | 0 | 31.3 | 0/0 | 0 | 2019 | 166 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.85 | 99.32 | 0.76 | 93.2 | 0 | 31.9 | 0/0 | 0 | 2017 | 171 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-13 | |
| TestTime | Test Time | 17:13 | |
| TestDuration | Duration | 1:26:51 | |
| pXar | pXar version | v2.2.5+88~g694c14c | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 5 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 5 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_tokenchain_count | Token Chain Length | 3 |
