Test Date: 2015-08-21 17:53
Analysis date: 2016-05-26 00:32
Analysis date: 2016-05-26 00:32
M2062 XRayHRQualification
Summary
| Module | Module | M2062 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 209 | |
| BumpBondingDefects | Bump Bonding Defects | 190 | |
| NoisyPixels | Noisy Pixels | 59 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 50/120 | 99.87/99.27 | % |
| Noise | Mean Noise | 162 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
8 | 0 | 99.88 | 99.29 | 0.39 | 70.6 | 8 | 23.7 | 0/0 | 0 | 1950 | 168 | 0 |
|
Chip 1
|
A
|
13 | 0 | 99.86 | 99.01 | 0.41 | 72.9 | 13 | 24.2 | 0/0 | 0 | 1944 | 172 | 0 |
|
Chip 2
|
A
|
5 | 0 | 99.85 | 99.39 | 0.51 | 62.4 | 5 | 20.5 | 0/0 | 0 | 1907 | 156 | 0 |
|
Chip 3
|
A
|
6 | 0 | 99.87 | 99.19 | 1.08 | 116.5 | 6 | 40.0 | 0/0 | 0 | 2050 | 164 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.84 | 99.08 | 0.72 | 121.2 | 0 | 41.6 | 0/0 | 0 | 2065 | 174 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.22 | 2.57 | 143.7 | 0 | 50.2 | 0/0 | 0 | 2128 | 162 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.89 | 99.33 | 0.49 | 142.6 | 0 | 49.2 | 0/0 | 0 | 2109 | 167 | 0 |
|
Chip 7
|
C
|
160 | 1 | 99.87 | 99.40 | 0.84 | 132.4 | 142 | 45.5 | 0/0 | 2+5/4 | 993 | 168 | 59 |
|
Chip 8
|
A
|
1 | 0 | 99.87 | 99.35 | 0.4 | 133.4 | 1 | 45.7 | 0/0 | 0 | 2073 | 160 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.89 | 99.36 | 0.33 | 137.4 | 0 | 47.4 | 0/0 | 0 | 2073 | 157 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.39 | 0.43 | 154.3 | 0 | 54.2 | 0/0 | 0 | 2148 | 162 | 0 |
|
Chip 11
|
A
|
2 | 0 | 99.87 | 99.35 | 0.62 | 132.0 | 2 | 45.5 | 0/0 | 0 | 2091 | 164 | 0 |
|
Chip 12
|
A
|
8 | 0 | 99.87 | 99.25 | 0.58 | 125.2 | 8 | 43.1 | 0/0 | 0 | 2078 | 169 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.87 | 99.37 | 0.29 | 67.1 | 1 | 22.1 | 0/0 | 0 | 1937 | 148 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.88 | 99.32 | 0.79 | 79.4 | 1 | 26.5 | 0/0 | 0 | 1986 | 151 | 0 |
|
Chip 15
|
A
|
3 | 0 | 99.83 | 98.99 | 0.46 | 65.9 | 3 | 21.8 | 0/0 | 0 | 1944 | 148 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-21 | |
| TestTime | Test Time | 17:53 | |
| TestDuration | Duration | 1:26:58 | |
| pXar | pXar version | v2.2.5+88~g694c14c | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 8 | |
| nWarnings | # Warnings | 3 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 11 | |
| message_eventid_count | Event ID mismatch | 4 | |
| message_tokenchain_count | Token Chain Length | 4 | |
| message_readback_count | Readback start marker | 3 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
