Test Date: 2015-08-12 14:10
Analysis date: 2016-05-26 00:17
Analysis date: 2016-05-26 00:17
M2058 XRayHRQualification
Summary
| Module | Module | M2058 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 11 | |
| BumpBondingDefects | Bump Bonding Defects | 7 | |
| NoisyPixels | Noisy Pixels | 3 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.25 | % |
| Noise | Mean Noise | 163 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
4 | 0 | 99.89 | 99.17 | 0.43 | 70.8 | 4 | 23.9 | 0/0 | 0 | 1991 | 181 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.84 | 98.95 | 0.41 | 68.0 | 0 | 22.5 | 0/0 | 0 | 1962 | 157 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.84 | 99.37 | 0.42 | 61.6 | 0 | 20.2 | 0/0 | 0 | 1962 | 173 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.85 | 99.34 | 0.8 | 118.4 | 0 | 40.5 | 0/0 | 0 | 2093 | 168 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.29 | 0.69 | 115.2 | 0 | 39.4 | 0/0 | 0 | 2063 | 160 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.31 | 0.84 | 133.6 | 0 | 46.4 | 0/0 | 0 | 2111 | 154 | 0 |
|
Chip 6
|
A
|
3 | 0 | 99.85 | 99.21 | 0.79 | 137.3 | 0 | 47.2 | 0/0 | 0 | 2049 | 168 | 3 |
|
Chip 7
|
A
|
0 | 0 | 99.83 | 99.27 | 0.89 | 140.8 | 0 | 48.2 | 0/0 | 0 | 2165 | 170 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.89 | 99.37 | 0.33 | 141.2 | 0 | 48.5 | 0/0 | 0 | 2143 | 156 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.88 | 99.33 | 1.11 | 152.8 | 0 | 53.0 | 0/0 | 0 | 2200 | 161 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.89 | 99.40 | 0.53 | 142.8 | 0 | 49.8 | 0/0 | 0 | 2149 | 151 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.32 | 1.13 | 127.0 | 0 | 44.0 | 0/0 | 0 | 2132 | 159 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.88 | 99.38 | 0.58 | 119.1 | 0 | 41.2 | 0/0 | 0 | 2108 | 156 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.86 | 99.35 | 0.43 | 73.1 | 0 | 24.4 | 0/0 | 0 | 2000 | 162 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 99.00 | 0.6 | 75.7 | 0 | 25.4 | 0/0 | 0 | 2023 | 162 | 0 |
|
Chip 15
|
A
|
3 | 0 | 99.82 | 98.97 | 0.67 | 77.0 | 3 | 26.1 | 0/0 | 0 | 2027 | 164 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-12 | |
| TestTime | Test Time | 14:10 | |
| TestDuration | Duration | 1:27:24 | |
| pXar | pXar version | v2.2.5+88~g694c14c | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 15 | |
| nWarnings | # Warnings | 13 | |
| channel_0_count | Channel 0 | 13 | |
| channel_1_count | Channel 1 | 10 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 5 | |
| message_eventid_count | Event ID mismatch | 3 | |
| message_tokenchain_count | Token Chain Length | 12 | |
| message_readback_count | Readback start marker | 13 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
