Test Date: 2015-08-11 09:36
Analysis date: 2016-05-26 00:11
Analysis date: 2016-05-26 00:11
M2057 XRayHRQualification
Summary
| Module | Module | M2057 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 32 | |
| BumpBondingDefects | Bump Bonding Defects | 29 | |
| NoisyPixels | Noisy Pixels | 3 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.34 | % |
| Noise | Mean Noise | 155 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.88 | 99.33 | 0.46 | 26.7 | 82.1 | 0 | 0/0 | 0 | 1982 | 156 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.85 | 99.11 | 1.09 | 29.1 | 88.9 | 0 | 0/0 | 0 | 1993 | 166 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.85 | 99.34 | 0.61 | 26.5 | 81.1 | 0 | 0/0 | 0 | 1972 | 149 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.39 | 0.75 | 47.4 | 138.3 | 0 | 0/0 | 0 | 2128 | 151 | 0 |
|
Chip 4
|
A
|
2 | 0 | 99.88 | 99.37 | 0.66 | 53.2 | 154.7 | 0 | 0/0 | 0 | 2062 | 157 | 2 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.37 | 0.41 | 61.2 | 175.7 | 0 | 0/0 | 0 | 2195 | 153 | 0 |
|
Chip 6
|
A
|
7 | 0 | 99.88 | 99.39 | 0.41 | 60.9 | 173.0 | 7 | 0/0 | 0 | 2188 | 156 | 0 |
|
Chip 7
|
A
|
15 | 0 | 99.87 | 99.38 | 0.71 | 63.3 | 183.9 | 15 | 0/0 | 0 | 2144 | 155 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.41 | 0.52 | 63.9 | 184.0 | 0 | 0/0 | 0 | 2247 | 153 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.39 | 0.65 | 57.1 | 166.8 | 0 | 0/0 | 0 | 2161 | 150 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.43 | 0.38 | 55.8 | 162.5 | 0 | 0/0 | 0 | 2170 | 147 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.37 | 0.54 | 52.9 | 154.8 | 0 | 0/0 | 0 | 2148 | 152 | 0 |
|
Chip 12
|
A
|
5 | 0 | 99.86 | 99.38 | 0.59 | 43.4 | 130.1 | 5 | 0/0 | 0 | 2091 | 149 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.87 | 99.42 | 0.34 | 27.6 | 84.1 | 1 | 0/0 | 0 | 2016 | 161 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 99.05 | 0.91 | 27.7 | 85.6 | 0 | 0/0 | 0 | 1999 | 158 | 0 |
|
Chip 15
|
A
|
2 | 0 | 99.87 | 99.34 | 0.68 | 29.6 | 90.2 | 1 | 0/0 | 0 | 1981 | 163 | 1 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-11 | |
| TestTime | Test Time | 09:36 | |
| TestDuration | Duration | 1:29:2 | |
| pXar | pXar version | v2.2.5+88~g694c14c | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 3 | |
| nWarnings | # Warnings | 3 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 6 | |
| message_eventid_count | Event ID mismatch | 1 | |
| message_tokenchain_count | Token Chain Length | 2 | |
| message_readback_count | Readback start marker | 3 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
