Test Date: 2015-08-18 09:38
Analysis date: 2016-05-25 23:59
Analysis date: 2016-05-25 23:59
M2055 XRayHRQualification
Summary
| Module | Module | M2055 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 4 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.30 | % |
| Noise | Mean Noise | 156 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.86 | 99.03 | 0.73 | 83.6 | 0 | 28.0 | 0/0 | 0 | 2010 | 154 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.87 | 99.32 | 0.66 | 94.0 | 0 | 31.5 | 0/0 | 0 | 2040 | 165 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.05 | 0.55 | 90.0 | 0 | 30.4 | 0/0 | 0 | 2033 | 159 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.31 | 0.44 | 152.3 | 0 | 53.4 | 0/0 | 0 | 2190 | 155 | 0 |
|
Chip 4
|
A
|
2 | 0 | 99.89 | 99.36 | 0.64 | 160.7 | 0 | 56.5 | 0/0 | 0 | 2180 | 154 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.40 | 0.83 | 190.0 | 0 | 68.1 | 0/0 | 0 | 2258 | 154 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.32 | 0.5 | 189.6 | 0 | 67.0 | 0/0 | 0 | 2263 | 159 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.40 | 0.69 | 212.3 | 0 | 75.2 | 0/0 | 0 | 2322 | 167 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.37 | 0.91 | 187.6 | 0 | 66.5 | 0/0 | 0 | 2259 | 161 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.86 | 99.35 | 0.76 | 165.2 | 0 | 58.7 | 0/0 | 0 | 2187 | 143 | 1 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.40 | 0.6 | 176.4 | 0 | 63.3 | 0/0 | 0 | 2225 | 150 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.89 | 99.42 | 0.49 | 166.1 | 0 | 58.0 | 0/0 | 0 | 2233 | 159 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.88 | 99.39 | 0.47 | 127.1 | 0 | 43.6 | 0/0 | 0 | 2120 | 147 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.86 | 99.36 | 0.29 | 89.9 | 0 | 30.1 | 0/0 | 0 | 2006 | 158 | 1 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 99.05 | 1.05 | 88.3 | 0 | 29.6 | 0/0 | 0 | 2031 | 155 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.87 | 99.33 | 0.45 | 77.7 | 0 | 25.8 | 0/0 | 0 | 2008 | 150 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-18 | |
| TestTime | Test Time | 09:38 | |
| TestDuration | Duration | 0:29:31 | |
| pXar | pXar version | v2.2.5+88~g694c14c | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 1 | |
| nWarnings | # Warnings | 1 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 2 | |
| message_tokenchain_count | Token Chain Length | 1 | |
| message_readback_count | Readback start marker | 1 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
