M2054 XRayHRQualification
Summary
| Module | Module | M2054 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 2 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.23 | % |
| Noise | Mean Noise | 162 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.86 | 99.01 | 0.72 | 70.8 | 0 | 23.6 | 0/0 | 0 | 1963 | 170 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.80 | 98.96 | 1.4 | 83.5 | 0 | 27.9 | 0/0 | 0 | 2011 | 179 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.84 | 99.32 | 0.4 | 78.5 | 0 | 26.1 | 0/0 | 0 | 1965 | 174 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.33 | 0.74 | 127.9 | 0 | 44.4 | 0/0 | 0 | 2121 | 165 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.85 | 99.20 | 0.69 | 128.2 | 1 | 44.4 | 0/0 | 0 | 2127 | 158 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.34 | 0.51 | 176.4 | 0 | 62.2 | 0/0 | 0 | 2216 | 165 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.90 | 99.32 | 0.61 | 150.1 | 0 | 52.4 | 0/0 | 0 | 2142 | 161 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.86 | 99.34 | 0.56 | 179.6 | 0 | 63.2 | 0/0 | 0 | 2215 | 159 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.89 | 99.38 | 0.54 | 153.7 | 0 | 53.8 | 0/0 | 0 | 2172 | 161 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.29 | 0.63 | 136.4 | 0 | 48.1 | 0/0 | 0 | 2135 | 153 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.88 | 99.39 | 0.44 | 143.6 | 1 | 50.5 | 0/0 | 0 | 2154 | 158 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.89 | 99.38 | 0.83 | 117.0 | 0 | 40.2 | 0/0 | 0 | 2070 | 151 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.84 | 99.10 | 1.32 | 105.5 | 0 | 36.2 | 0/0 | 0 | 2070 | 155 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.85 | 99.08 | 0.47 | 64.8 | 0 | 21.4 | 0/0 | 0 | 1962 | 159 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.87 | 99.16 | 0.54 | 69.8 | 0 | 23.2 | 0/0 | 0 | 1965 | 161 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.84 | 99.01 | 0.38 | 68.3 | 0 | 22.8 | 0/0 | 0 | 1976 | 167 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-11 | |
| TestTime | Test Time | 09:36 | |
| TestDuration | Duration | 1:29:2 | |
| pXar | pXar version | v2.2.5+88~g694c14c | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 4 | |
| nWarnings | # Warnings | 1 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 5 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_tokenchain_count | Token Chain Length | 2 | |
| message_readback_count | Readback start marker | 1 |
