Test Date: 2015-09-17 11:03
Analysis date: 2016-05-25 23:47
Analysis date: 2016-05-25 23:47
M2053 XRayHRQualification
Summary
| Module | Module | M2053 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 16 | |
| BumpBondingDefects | Bump Bonding Defects | 15 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.26 | % |
| Noise | Mean Noise | 173 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
8 | 0 | 99.86 | 99.16 | 0.5 | 80.5 | 8 | 27.3 | 0/0 | 0 | 1983 | 165 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 98.96 | 0.93 | 85.5 | 0 | 28.8 | 0/0 | 0 | 1984 | 166 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.87 | 99.32 | 0.39 | 75.5 | 0 | 25.2 | 0/0 | 0 | 1968 | 162 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.86 | 99.31 | 0.55 | 136.6 | 0 | 47.5 | 0/0 | 0 | 2123 | 165 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.23 | 0.71 | 157.1 | 0 | 54.1 | 0/0 | 0 | 2169 | 187 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.39 | 0.75 | 176.8 | 0 | 62.4 | 0/0 | 0 | 2239 | 179 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.36 | 0.82 | 174.5 | 0 | 60.7 | 0/0 | 0 | 2235 | 188 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.85 | 99.32 | 1.45 | 181.1 | 0 | 63.1 | 0/0 | 0 | 2235 | 176 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.89 | 99.39 | 0.36 | 174.1 | 0 | 60.2 | 0/0 | 0 | 2224 | 191 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.89 | 99.40 | 1.0 | 147.9 | 0 | 51.6 | 0/0 | 0 | 2146 | 175 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.90 | 99.37 | 0.4 | 158.5 | 0 | 55.7 | 0/0 | 0 | 2194 | 173 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.87 | 99.33 | 0.72 | 131.8 | 1 | 45.5 | 0/0 | 0 | 2131 | 171 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.86 | 99.01 | 1.52 | 114.1 | 1 | 39.1 | 0/0 | 0 | 2061 | 170 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.86 | 99.17 | 0.35 | 69.0 | 0 | 22.7 | 0/0 | 0 | 1963 | 170 | 0 |
|
Chip 14
|
A
|
2 | 0 | 99.88 | 99.22 | 0.31 | 74.5 | 2 | 24.6 | 0/0 | 0 | 1968 | 163 | 0 |
|
Chip 15
|
A
|
4 | 0 | 99.87 | 99.19 | 0.54 | 73.6 | 3 | 24.7 | 0/0 | 0 | 1932 | 162 | 1 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-09-17 | |
| TestTime | Test Time | 11:03 | |
| TestDuration | Duration | 1:13:7 | |
| pXar | pXar version | prod-10+28~ga8f1456 | |
| DTB_FW | DTB FW | 4.4 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
