Test Date: 2015-08-12 14:10
Analysis date: 2016-05-25 23:41
Analysis date: 2016-05-25 23:41
M2052 XRayHRQualification
Summary
| Module | Module | M2052 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 2 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.32 | % |
| Noise | Mean Noise | 157 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.88 | 99.35 | 0.55 | 86.1 | 0 | 29.0 | 0/0 | 0 | 2055 | 161 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.85 | 99.28 | 0.96 | 95.3 | 0 | 32.0 | 0/0 | 0 | 2072 | 159 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.03 | 0.6 | 80.1 | 0 | 26.1 | 0/0 | 0 | 1996 | 154 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.89 | 99.33 | 0.64 | 159.9 | 0 | 56.0 | 0/0 | 0 | 2217 | 162 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.39 | 0.68 | 150.4 | 0 | 52.2 | 0/0 | 0 | 2169 | 157 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.89 | 99.33 | 0.58 | 167.6 | 0 | 58.6 | 0/0 | 0 | 2182 | 149 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.36 | 0.37 | 159.8 | 0 | 55.4 | 0/0 | 0 | 2180 | 151 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.86 | 99.39 | 0.38 | 182.3 | 1 | 64.2 | 0/0 | 0 | 2256 | 157 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.87 | 99.38 | 0.4 | 181.1 | 0 | 63.3 | 0/0 | 0 | 2208 | 161 | 1 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.38 | 0.92 | 165.1 | 0 | 57.2 | 0/0 | 0 | 2221 | 154 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.28 | 0.57 | 175.8 | 0 | 61.6 | 0/0 | 0 | 2211 | 153 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.37 | 0.49 | 154.8 | 0 | 53.6 | 0/0 | 0 | 2207 | 162 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.34 | 0.55 | 143.4 | 0 | 49.8 | 0/0 | 0 | 2160 | 155 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.85 | 99.19 | 0.38 | 89.1 | 0 | 29.6 | 0/0 | 0 | 2057 | 161 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.86 | 99.35 | 0.77 | 95.8 | 0 | 32.2 | 0/0 | 0 | 2088 | 162 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.88 | 99.36 | 0.49 | 84.1 | 0 | 28.0 | 0/0 | 0 | 2039 | 153 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-12 | |
| TestTime | Test Time | 14:10 | |
| TestDuration | Duration | 1:27:24 | |
| pXar | pXar version | v2.2.5+88~g694c14c | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 1 | |
| nErrors | # Errors | 6 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 3 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 3 | |
| message_eventid_count | Event ID mismatch | 4 | |
| message_missingevents_count | Missing Event criticals | 1 | |
| message_tokenchain_count | Token Chain Length | 2 |
