Test Date: 2015-09-10 11:57
Analysis date: 2016-05-25 23:23
Analysis date: 2016-05-25 23:23
M2049 XRayHRQualification
Summary
| Module | Module | M2049 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.26 | % |
| Noise | Mean Noise | 163 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.87 | 99.28 | 0.41 | 76.1 | 0 | 26.1 | 0/0 | 0 | 1977 | 170 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.88 | 99.25 | 0.66 | 83.5 | 0 | 28.3 | 0/0 | 0 | 1980 | 181 | 0 |
|
Chip 2
|
A
|
1 | 0 | 99.87 | 99.28 | 0.47 | 75.9 | 0 | 25.6 | 0/0 | 0 | 1990 | 174 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.34 | 0.67 | 123.2 | 0 | 43.1 | 0/0 | 0 | 2097 | 162 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.32 | 0.64 | 126.1 | 0 | 43.9 | 0/0 | 0 | 2097 | 164 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.37 | 0.53 | 151.3 | 0 | 53.5 | 0/0 | 0 | 2176 | 157 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.27 | 0.47 | 161.0 | 0 | 55.8 | 0/0 | 0 | 2180 | 160 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.88 | 99.33 | 0.6 | 159.0 | 0 | 55.5 | 0/0 | 0 | 2203 | 157 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.86 | 99.28 | 0.57 | 128.1 | 0 | 43.9 | 0/0 | 0 | 2113 | 152 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.89 | 99.35 | 0.68 | 135.2 | 0 | 47.0 | 0/0 | 0 | 2118 | 168 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.35 | 0.54 | 128.0 | 0 | 44.6 | 0/0 | 0 | 2118 | 154 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.32 | 0.88 | 133.3 | 0 | 45.9 | 0/0 | 0 | 2161 | 162 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.88 | 99.24 | 0.81 | 104.9 | 0 | 36.1 | 0/0 | 0 | 2055 | 159 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.85 | 99.19 | 0.46 | 63.6 | 0 | 21.2 | 0/0 | 0 | 1954 | 167 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 98.97 | 0.41 | 65.9 | 0 | 22.1 | 0/0 | 0 | 1959 | 152 | 0 |
|
Chip 15
|
A
|
2 | 0 | 99.85 | 98.99 | 1.54 | 66.0 | 0 | 22.4 | 0/0 | 0 | 1945 | 165 | 1 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-09-10 | |
| TestTime | Test Time | 11:57 | |
| TestDuration | Duration | 0:19:26 | |
| pXar | pXar version | prod-10+24~g09f6d2c | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 9 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 1 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 1 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
