Test Date: 2015-08-11 16:58
Analysis date: 2016-05-25 22:59
Analysis date: 2016-05-25 22:59
M2045 XRayHRQualification
Summary
| Module | Module | M2045 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 7 | |
| BumpBondingDefects | Bump Bonding Defects | 6 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.31 | % |
| Noise | Mean Noise | 155 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.88 | 99.30 | 0.41 | 68.5 | 0 | 23.0 | 0/0 | 0 | 1961 | 155 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.87 | 99.24 | 0.38 | 73.5 | 0 | 24.6 | 0/0 | 0 | 1984 | 148 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.87 | 99.41 | 0.48 | 70.6 | 0 | 23.6 | 0/0 | 0 | 1966 | 155 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.37 | 0.76 | 122.8 | 0 | 43.0 | 0/0 | 0 | 2104 | 152 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.89 | 99.35 | 0.58 | 126.8 | 0 | 43.8 | 0/0 | 0 | 2112 | 155 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.90 | 99.36 | 0.47 | 140.8 | 0 | 48.7 | 0/0 | 0 | 2121 | 149 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.89 | 99.43 | 0.63 | 157.0 | 0 | 55.0 | 0/0 | 0 | 2210 | 159 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.88 | 99.38 | 0.35 | 152.3 | 0 | 52.8 | 0/0 | 0 | 2152 | 151 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.88 | 99.35 | 0.32 | 134.0 | 0 | 45.7 | 0/0 | 0 | 2080 | 148 | 1 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.36 | 0.51 | 142.5 | 0 | 49.4 | 0/0 | 0 | 2142 | 153 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.36 | 0.79 | 151.8 | 0 | 53.7 | 0/0 | 0 | 2171 | 160 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.38 | 0.44 | 122.1 | 0 | 42.2 | 0/0 | 0 | 2089 | 155 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.88 | 99.29 | 0.74 | 114.5 | 0 | 39.5 | 0/0 | 0 | 2075 | 155 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.86 | 99.42 | 0.45 | 63.3 | 1 | 21.0 | 0/0 | 0 | 1954 | 155 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.83 | 98.97 | 0.44 | 71.3 | 1 | 23.9 | 0/0 | 0 | 1999 | 159 | 0 |
|
Chip 15
|
A
|
4 | 0 | 99.85 | 99.04 | 0.53 | 68.0 | 4 | 23.0 | 0/0 | 0 | 1970 | 162 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-11 | |
| TestTime | Test Time | 16:58 | |
| TestDuration | Duration | 1:26:55 | |
| pXar | pXar version | v2.2.5+88~g694c14c | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 1 | |
| nErrors | # Errors | 204 | |
| nWarnings | # Warnings | 230 | |
| channel_0_count | Channel 0 | 116 | |
| channel_1_count | Channel 1 | 152 | |
| channel_2_count | Channel 2 | 88 | |
| channel_3_count | Channel 3 | 78 | |
| message_eventid_count | Event ID mismatch | 46 | |
| message_missingevents_count | Missing Event criticals | 1 | |
| message_tokenchain_count | Token Chain Length | 158 | |
| message_readback_count | Readback start marker | 230 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
