Test Date: 2015-08-21 11:04
Analysis date: 2016-05-25 22:53
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
47.525375 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
47.525375 |
|
| medianSlope |
median Slope |
47.8005 |
|
| minSlope |
min Slope |
44.19 |
|
| maxSlope |
max Slope |
50.089 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-120.4738125 |
|
| medianOffset |
median Offset |
-188.405 |
|
| minOffset |
min Offset |
-338.307 |
|
| maxOffset |
max Offset |
164.012 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
3.8870625 |
|
| medianchi2 |
median chi2 |
1.568 |
|
| minchi2 |
min chi2 |
0.002 |
|
| maxchi2 |
max chi2 |
19.091 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
49.4 e- / Vcal
|
0.1 e- / Vcal
|
-210.7 e-
|
8.3 e-
|
|
1
|
46.6 e- / Vcal
|
0.2 e- / Vcal
|
5.5 e-
|
19.8 e-
|
|
2
|
44.6 e- / Vcal
|
0.2 e- / Vcal
|
-234.8 e-
|
22.9 e-
|
|
3
|
45.8 e- / Vcal
|
0.1 e- / Vcal
|
164.0 e-
|
14.4 e-
|
|
4
|
49.3 e- / Vcal
|
0.1 e- / Vcal
|
133.3 e-
|
7.0 e-
|
|
5
|
48.2 e- / Vcal
|
0.1 e- / Vcal
|
22.3 e-
|
7.0 e-
|
|
6
|
46.8 e- / Vcal
|
0.1 e- / Vcal
|
-221.7 e-
|
16.9 e-
|
|
7
|
45.2 e- / Vcal
|
0.1 e- / Vcal
|
-226.4 e-
|
16.5 e-
|
|
8
|
44.2 e- / Vcal
|
0.1 e- / Vcal
|
-192.1 e-
|
18.6 e-
|
|
9
|
47.2 e- / Vcal
|
0.2 e- / Vcal
|
24.3 e-
|
18.2 e-
|
|
10
|
47.4 e- / Vcal
|
0.1 e- / Vcal
|
-75.6 e-
|
5.1 e-
|
|
11
|
48.7 e- / Vcal
|
0.1 e- / Vcal
|
-184.7 e-
|
6.6 e-
|
|
12
|
48.7 e- / Vcal
|
0.1 e- / Vcal
|
-256.0 e-
|
6.7 e-
|
|
13
|
50.1 e- / Vcal
|
0.2 e- / Vcal
|
-112.6 e-
|
17.7 e-
|
|
14
|
49.6 e- / Vcal
|
0.1 e- / Vcal
|
-224.0 e-
|
7.6 e-
|
|
15
|
48.6 e- / Vcal
|
0.2 e- / Vcal
|
-338.3 e-
|
19.8 e-
|
|
Average
|
47.5 e- / Vcal
|
|
-120.5 e-
|
|
|
Median
|
89.4 e- / Vcal
|
|
-418.5 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
