Test Date: 2015-08-21 11:04
Analysis date: 2016-05-25 22:53
Chip 15
Grading
ROCGrade Final ROC Grade A
NumberOfHotPixels # Hot Pixels 150/50 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 150/50 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 150/50 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 150/50 0/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 150/50 0/0
Efficiency Efficiency 50/120 99.83/98.97
EfficiencyFit Efficiency Fit chi2/ndf: 0.88, # points: 93
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 150/50 A/A
HitMapGrade Hit Map Grade 150/50 A/(A)
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 150/50 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 150/50 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade A
Efficiency Interpolation: C15
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.88
NumberFitPoints # fit points 93
p0 p0 99.89
p1 p1 5.35e-07
InterpolatedEfficiency50 Interpol. Efficiency 50 99.83
InterpolatedEfficiency120 Interpol. Efficiency 120 98.97
Efficiency Map 50: C15
Efficiency Map 100: C15
Efficiency Map 150: C15
Efficiency Map 200: C15
Efficiency Map 250: C15
Efficiency Distr. 50: C15
Plot
N N 4160
mu μ 99.87
sigma σ 2.23
Efficiency Distr. 100: C15
Plot
N N 4160
mu μ 99.66
sigma σ 2.32
Efficiency Distr. 150: C15
Plot
N N 4160
mu μ 99.19
sigma σ 2.56
Efficiency Distr. 200: C15
Plot
N N 4160
mu μ 98.24
sigma σ 3.13
Efficiency Distr. 250: C15
Plot
N N 4160
mu μ 98.14
sigma σ 3.21
Background Map 50: C15
Plot
RealHitrate Real Hitrate 33.72 MHz/cm2
Background Map 100: C15
Plot
RealHitrate Real Hitrate 67.67 MHz/cm2
Background Map 150: C15
Plot
RealHitrate Real Hitrate 97.56 MHz/cm2
Background Map 200: C15
Plot
RealHitrate Real Hitrate 131.73 MHz/cm2
Background Map 250: C15
Plot
RealHitrate Real Hitrate 134.83 MHz/cm2
Retrim Hot Pix 150: C15
Masked Hot Pixels 150: C15
Masked Hot Pixels 50: C15
Hit Map 150: C15
Plot
RealHitrate Real Hitrate 95.35 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 150: C15
Hit Map 50: C15
Plot
RealHitrate Real Hitrate 32.63 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 50: C15
Col. Read. Unif. 150: C15
Plot
N N 13455733
mu μ 296598
sigma σ 80322.70
Col. Read. Unif. 50: C15
Plot
N N 4590036
mu μ 101525
sigma σ 29250.57
Read. Unif. over Time 150: C15
Plot
N N 15423083
mu μ 15626
sigma_th σ_th 125.00
Time unif. distribution 150: C15
Plot
chi2/ndf chi2/ndf 2.23
sigma σ 135.09
sigma_th σ_th 125.06
expectation Red curve (expected) Poisson
Read. Unif. over Time 50: C15
Plot
N N 5279320
mu μ 5349
sigma_th σ_th 73.14
Time unif. distribution 50: C15
Plot
chi2/ndf chi2/ndf 1.20
sigma σ 77.31
sigma_th σ_th 73.16
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C15
Col. Uniformity per Event: C15 150
Plot
mu μ 26.19
sigma fit error of μ 2.21
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
Col. Uniformity per Event: C15 50
Plot
mu μ 26.08
sigma fit error of μ 2.24
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C15 100
Plot
N N 4158
mu μ 171.90
sigma RMS 16.16
threshold thr 2009.61
fit fit Gaussian
fit_peak μ fit 171.47
fit_sigma σ fit 15.73
MeasuredHitrate Measured hitrate: 67.1
under <= 1.00
over >= 1.00
Alive Map: C15
DC Efficiency Distribution: C15
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.86
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 98.96
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C15
