Test Date: 2015-08-21 11:04
Analysis date: 2016-05-25 22:53
Chip 12
Grading
ROCGrade Final ROC Grade A
NumberOfHotPixels # Hot Pixels 150/50 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 150/50 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 150/50 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 150/50 0/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 150/50 0/0
Efficiency Efficiency 50/120 99.89/99.27
EfficiencyFit Efficiency Fit chi2/ndf: 0.62, # points: 62
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 150/50 A/A
HitMapGrade Hit Map Grade 150/50 A/(A)
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 150/50 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 150/50 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade A
Efficiency Interpolation: C12
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.62
NumberFitPoints # fit points 62
p0 p0 99.94
p1 p1 3.83e-07
InterpolatedEfficiency50 Interpol. Efficiency 50 99.89
InterpolatedEfficiency120 Interpol. Efficiency 120 99.27
Efficiency Map 50: C12
Efficiency Map 100: C12
Efficiency Map 150: C12
Efficiency Map 200: C12
Efficiency Map 250: C12
Efficiency Distr. 50: C12
Plot
N N 4160
mu μ 99.87
sigma σ 0.49
Efficiency Distr. 100: C12
Plot
N N 4160
mu μ 99.42
sigma σ 1.17
Efficiency Distr. 150: C12
Plot
N N 4160
mu μ 98.48
sigma σ 2.16
Efficiency Distr. 200: C12
Plot
N N 4160
mu μ 96.33
sigma σ 4.07
Efficiency Distr. 250: C12
Plot
N N 4160
mu μ 96.08
sigma σ 4.29
Background Map 50: C12
Plot
RealHitrate Real Hitrate 50.52 MHz/cm2
Background Map 100: C12
Plot
RealHitrate Real Hitrate 100.96 MHz/cm2
Background Map 150: C12
Plot
RealHitrate Real Hitrate 145.09 MHz/cm2
Background Map 200: C12
Plot
RealHitrate Real Hitrate 194.71 MHz/cm2
Background Map 250: C12
Plot
RealHitrate Real Hitrate 201.04 MHz/cm2
Retrim Hot Pix 150: C12
Masked Hot Pixels 150: C12
Masked Hot Pixels 50: C12
Hit Map 150: C12
Plot
RealHitrate Real Hitrate 141.30 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 150: C12
Hit Map 50: C12
Plot
RealHitrate Real Hitrate 48.80 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 50: C12
Col. Read. Unif. 150: C12
Plot
N N 20006763
mu μ 439534
sigma σ 116169.29
Col. Read. Unif. 50: C12
Plot
N N 6896571
mu μ 151833
sigma σ 42411.03
Read. Unif. over Time 150: C12
Plot
N N 22855763
mu μ 23157
sigma_th σ_th 152.17
Time unif. distribution 150: C12
Plot
chi2/ndf chi2/ndf 5.26
sigma σ 165.95
sigma_th σ_th 152.24
expectation Red curve (expected) Poisson
Read. Unif. over Time 50: C12
Plot
N N 7895309
mu μ 7999
sigma_th σ_th 89.44
Time unif. distribution 50: C12
Plot
chi2/ndf chi2/ndf 0.69
sigma σ 93.05
sigma_th σ_th 89.47
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C12
Col. Uniformity per Event: C12 150
Plot
mu μ 26.29
sigma fit error of μ 2.19
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
Col. Uniformity per Event: C12 50
Plot
mu μ 26.52
sigma fit error of μ 2.20
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C12 100
Plot
N N 4160
mu μ 157.55
sigma RMS 15.24
threshold thr 2128.66
fit fit Gaussian
fit_peak μ fit 157.03
fit_sigma σ fit 14.58
MeasuredHitrate Measured hitrate: 100.6
Alive Map: C12
DC Efficiency Distribution: C12
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.88
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.29
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C12
