Test Date: 2015-08-11 15:16
Analysis date: 2016-05-25 22:35
Analysis date: 2016-05-25 22:35
M2041 XRayHRQualification
Summary
| Module | Module | M2041 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 13 | |
| BumpBondingDefects | Bump Bonding Defects | 9 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.24 | % |
| Noise | Mean Noise | 163 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.86 | 98.94 | 0.51 | 71.5 | 0 | 23.7 | 0/0 | 0 | 1972 | 165 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.87 | 99.25 | 0.59 | 75.7 | 0 | 24.9 | 0/0 | 0 | 1962 | 168 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.87 | 99.34 | 0.58 | 65.5 | 0 | 21.3 | 0/0 | 0 | 1932 | 163 | 0 |
|
Chip 3
|
A
|
1 | 0 | 99.88 | 99.29 | 1.27 | 122.6 | 0 | 42.1 | 0/0 | 0 | 2102 | 163 | 0 |
|
Chip 4
|
A
|
2 | 0 | 99.87 | 99.28 | 1.09 | 137.1 | 0 | 47.2 | 0/0 | 0 | 2123 | 169 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.30 | 0.67 | 164.9 | 0 | 57.9 | 0/0 | 0 | 2198 | 170 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.87 | 99.34 | 0.61 | 146.8 | 0 | 50.9 | 0/0 | 0 | 2145 | 158 | 0 |
|
Chip 7
|
A
|
7 | 0 | 99.88 | 99.32 | 0.57 | 141.5 | 7 | 48.8 | 0/0 | 0 | 2121 | 161 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.24 | 1.0 | 140.5 | 0 | 47.9 | 0/0 | 0 | 2100 | 170 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.85 | 99.16 | 0.54 | 133.3 | 0 | 45.8 | 0/0 | 0 | 2097 | 156 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.33 | 0.45 | 141.2 | 0 | 49.2 | 0/0 | 0 | 2129 | 161 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.19 | 0.82 | 116.3 | 0 | 39.6 | 0/0 | 0 | 2094 | 160 | 0 |
|
Chip 12
|
A
|
2 | 0 | 99.86 | 99.35 | 0.68 | 107.9 | 2 | 36.5 | 0/0 | 0 | 2061 | 167 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.26 | 1.93 | 60.5 | 0 | 19.6 | 0/0 | 0 | 1920 | 162 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.87 | 99.17 | 0.53 | 67.4 | 0 | 21.9 | 0/0 | 0 | 1958 | 162 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.89 | 99.13 | 0.29 | 62.7 | 0 | 20.6 | 0/0 | 0 | 1935 | 155 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-11 | |
| TestTime | Test Time | 15:16 | |
| TestDuration | Duration | 1:28:57 | |
| pXar | pXar version | v2.2.5+88~g694c14c | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 2 | |
| nWarnings | # Warnings | 1 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 3 | |
| message_tokenchain_count | Token Chain Length | 2 | |
| message_readback_count | Readback start marker | 1 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
