Test Date: 2015-07-07 08:06
Analysis date: 2016-05-25 21:35
Analysis date: 2016-05-25 21:35
M2031 XRayHRQualification
Summary
| Module | Module | M2031 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 45 | |
| BumpBondingDefects | Bump Bonding Defects | 43 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.22 | % |
| Noise | Mean Noise | 169 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.86 | 99.00 | 0.42 | 23.5 | 69.6 | 1 | 0/0 | 0 | 1928 | 174 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 98.93 | 0.56 | 23.0 | 68.9 | 0 | 0/0 | 0 | 1903 | 167 | 0 |
|
Chip 2
|
A
|
1 | 0 | 99.88 | 99.34 | 0.46 | 20.9 | 63.3 | 1 | 0/0 | 0 | 1876 | 170 | 0 |
|
Chip 3
|
A
|
4 | 0 | 99.85 | 99.29 | 0.85 | 42.1 | 122.6 | 2 | 0/0 | 0 | 1993 | 178 | 2 |
|
Chip 4
|
A
|
19 | 0 | 99.84 | 99.15 | 3.55 | 39.6 | 115.8 | 19 | 0/0 | 0 | 2047 | 166 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.89 | 99.29 | 0.56 | 47.8 | 137.1 | 0 | 0/0 | 0 | 2112 | 162 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.33 | 0.86 | 45.2 | 131.3 | 0 | 0/0 | 0 | 2100 | 174 | 0 |
|
Chip 7
|
A
|
13 | 0 | 99.87 | 99.37 | 0.67 | 42.8 | 125.3 | 13 | 0/0 | 0 | 2115 | 172 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.88 | 99.32 | 0.57 | 44.7 | 131.9 | 1 | 0/0 | 0 | 2075 | 170 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.88 | 99.25 | 0.93 | 49.1 | 142.4 | 1 | 0/0 | 0 | 2051 | 173 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.85 | 99.26 | 0.88 | 53.0 | 151.3 | 1 | 0/0 | 0 | 2093 | 173 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.28 | 0.6 | 41.5 | 120.7 | 0 | 0/0 | 0 | 2026 | 161 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.29 | 1.25 | 41.1 | 119.0 | 0 | 0/0 | 0 | 2009 | 178 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.86 | 99.29 | 0.54 | 24.0 | 72.2 | 0 | 0/0 | 0 | 1907 | 169 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.84 | 98.99 | 0.49 | 22.7 | 68.5 | 1 | 0/0 | 0 | 1909 | 159 | 0 |
|
Chip 15
|
A
|
3 | 0 | 99.88 | 99.21 | 0.47 | 25.3 | 74.5 | 3 | 0/0 | 0 | 1904 | 160 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-07-07 | |
| TestTime | Test Time | 08:06 | |
| TestDuration | Duration | 0:24:50 | |
| pXar | pXar version | v2.2.5+45~gbf85984 | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 12 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_tokenchain_count | Token Chain Length | 12 | |
| message_readback_count | Readback start marker | 12 |
