Test Date: 2015-08-18 11:20
Analysis date: 2016-05-25 21:13
M2028 ModuleFulltestPxar_m20_2
Chips

Overview

_
Summary 1
Module Module M2028
Grade Grade A
ElectricalGrade Electrical Grade A
IVGrade IV Grade A
ManualGrade Manual Grade None
PixelDefects Pixel Defects - A/B/C 44 - 16/0/0
DeadPixels Dead Pixels 0
AddressProblems Address Problems 0
ThresholdDefects Threshold Defects 5
MaskDefects Mask Defects 0
DeadBumps Dead Bumps 38
NoisyPixels Noise Defects 1
TrimProblems Trim Problems 0
PHGainDefects PH Gain Defects 0
PHPar1Defects PH Parameter1 Defects 0
Summary 2
TestCenter Test Center ETH
TestDate Test Date 2015-08-18
TestTime Test Time 11:20
TestDuration Duration 1:14:56
TempC Temparature -20 °C
TBM1 TBM1 ok, 0x6c 0x40
TBM2 TBM2 ok, 0x00 0x49
PxarVersion pXar v2.2.5+88 g694c14c
DTB_FW DTB FW 4.0
ModuleIa Module Ia 376.2 mA
Summary 3
Noise Noise 115.41 e
NoiseROCs Noise grades 16/0/0
VcalThrWidth Vcal Thr. Width 51.44 e
VcalThrWidthROCs Vcal Thr. W. grades 16/0/0
RelGainWidth Rel. Gain Width 0.03 %
RelGainWidthROCs Rel. Gain W. grades 16/0/0
PedestalSpread Pedestal Spread 1102.53 e
PedestalSpreadROCs Ped. Spread grades 16/0/0
Parameter1 Parameter1 0.71
Parameter1ROCs Par1 grades 16/0/0
CurrentAtVoltage150V I_rec(150 V) @ 17°C 8.02 μA
CurrentAtVoltage150V_ORIG I_orig(150V) @ -20.0 °C 0.18 μA
CurrentVariation I(150 V) / I(100 V) 2.34
IVCurve
CurrentAtVoltage150V I_orig(150V) @ -20.0 °C 0.18 μA
Variation I(150 V) / I(100 V) 2.34
recalculatedCurrentAtVoltage150V I_rec(150 V) @ 17°C 8.02 μA
recalculatedCurrentVariation I_rec(150 V) / I_rec(100 V) 2.34
CurrentRatio100V I(+17C)/I(-20C) 100V 5.69
CurrentRatio150V I(+17C)/I(-20C) 150V 3.20
Noise
Vcal Threshold Width
RelativeGainWidth
PedestalSpread
Parameter1
CalDel
mu μ 141.19
caldelspread CalDel spread 42
PHScale
mu μ 81.31
phscalespread PHScale spread 19
PHOffset
mu μ 157.19
phoffsetspread PHOffset spread 36
VthrComp
mu μ 87.12
vthrcompspread VthrComp spread 30
Vtrim
mu μ 110.38
vtrimspread Vtrim spread 51
Vana
mu μ 78.69
vanaspread Vana spread 24
Digital Current
Duration Duration 1:14:56
MinCurrent min. Current 0.441 A
MaxCurrent max. Current 0.474 A
Analog Current
Duration Duration 1:14:56
MinCurrent min. Current 0.37 A
MaxCurrent max. Current 0.38 A
ModuleIa Module Ia 376.2 mA
Temperature
Temperature Temp. while test -20.00 +/- 0.01 °C
Duration Duration of test 0:08:36
Summary ROCs
ROC Grade Total Dead Mask Bumps Trim(Bits) Address Noise Thresh Gain Ped Par1 Mean noise Thr [e-] Thr width Rel gain width Ped spread
Chip 0
A
0
0
0
0
0
0
0
0
0
0
0
108.83
1752
48
0.028
1283
Chip 1
A
1
0
0
0
0
0
0
1
0
0
0
125.29
1752
52
0.025
1116
Chip 2
A
0
0
0
0
0
0
0
0
0
0
0
107.84
1754
49
0.032
956
Chip 3
A
0
0
0
0
0
0
0
0
0
0
0
116.88
1754
49
0.026
966
Chip 4
A
1
0
0
0
0
0
0
1
0
0
0
133.37
1754
55
0.033
1062
Chip 5
A
0
0
0
0
0
0
0
0
0
0
0
102.54
1752
49
0.037
1170
Chip 6
A
2
0
0
0
0
0
1
1
0
0
0
91.63
1752
48
0.028
894
Chip 7
A
31
0
0
30
0
0
0
1
0
0
0
111.23
1753
50
0.035
1250
Chip 8
A
4
0
0
4
0
0
0
0
0
0
0
123.63
1754
55
0.034
1144
Chip 9
A
0
0
0
0
0
0
0
0
0
0
0
100.65
1754
50
0.039
882
Chip 10
A
0
0
0
0
0
0
0
0
0
0
0
129.71
1753
55
0.031
1138
Chip 11
A
0
0
0
0
0
0
0
0
0
0
0
128.00
1753
54
0.033
1322
Chip 12
A
0
0
0
0
0
0
0
0
0
0
0
125.81
1752
54
0.027
1206
Chip 13
A
1
0
0
1
0
0
0
0
0
0
0
98.92
1752
50
0.035
1032
Chip 14
A
1
0
0
1
0
0
0
0
0
0
0
112.22
1751
50
0.034
1075
Chip 15
A
3
0
0
2
0
0
0
1
0
0
0
130.08
1758
55
0.040
1144
Readback par0vd
Readback par1vd
Readback par0va
Readback par1va
Readback par0rbia
Readback par1rbia
Readback par0tbia
Readback par1tbia
Readback par2tbia
Readback par0ia
Readback par1ia
Readback par2ia
GradingParameters
ModifiedGrading Modified Grading True
GradingParameters_leakageCurrentRatioB leakageCurrentRatioB 20 => -111
TBM
nTBMs n 1
TBMType Type tbm09c
Core0a_basea Core 0a base a 0x40
Core0a_basee Core 0a base e 0x6c
Core0b_basea Core 0b base a 0x49
Core0b_basee Core 0b base e 0x00
RocDelay_Ch0 Roc Delay Ch0 0
RocDelay_Ch1 Roc Delay Ch1 0
RocDelay_Ch2 Roc Delay Ch2 1
RocDelay_Ch3 Roc Delay Ch3 1
Phase400 Phase 400 3
Phase160 Phase 160 3
Logfile

Overview

Errors
nCriticals # Criticals 0
nErrors # Errors 29
nWarnings # Warnings 20
channel_0_count Channel 0 0
channel_1_count Channel 1 0
channel_2_count Channel 2 0
channel_3_count Channel 3 49
message_eventid_count Event ID mismatch 9
message_readback_count Readback start marker 20
message_tokenchain_count Token Chain Length 20
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
