Test Date: 2016-11-14 09:30
Analysis date: 2016-11-14 10:21
Analysis date: 2016-11-14 10:21
M1137 XRayHRQualification
Summary
| Module | Module | M1137 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 0 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.58 | % |
| Noise | Mean Noise | 354 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.60 | 0.38 | 246.6 | 0 | 80.0 | 0/0 | 0 | 3656 | 366 | 1275 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.58 | 0.29 | 198.1 | 0 | 63.5 | 0/0 | 0 | 3719 | 335 | 785 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.61 | 0.26 | 192.5 | 0 | 62.6 | 0/0 | 0 | 3731 | 335 | 822 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.58 | 0.24 | 156.8 | 0 | 51.5 | 0/0 | 0 | 3695 | 345 | 959 |
|
Chip 4
|
A
|
0 | 0 | 99.81 | 99.86 | 0.22 | 117.7 | 0 | 38.7 | 0/0 | 0 | 3774 | 314 | 561 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.41 | 0.24 | 160.6 | 0 | 52.1 | 0/0 | 0 | 3714 | 340 | 831 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 99.40 | 0.25 | 153.3 | 0 | 50.1 | 0/0 | 0 | 3715 | 359 | 1151 |
|
Chip 7
|
A
|
0 | 0 | 99.81 | 99.52 | 0.26 | 171.5 | 0 | 55.7 | 0/0 | 0 | 3658 | 377 | 1420 |
|
Chip 8
|
A
|
0 | 0 | 99.78 | 99.68 | 0.33 | 162.2 | 0 | 52.4 | 0/0 | 0 | 3723 | 360 | 1134 |
|
Chip 9
|
A
|
0 | 0 | 99.83 | 99.74 | 0.21 | 146.5 | 0 | 47.8 | 0/0 | 0 | 3748 | 330 | 759 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.59 | 0.3 | 201.2 | 0 | 65.6 | 0/0 | 0 | 3630 | 354 | 1115 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.57 | 0.2 | 147.4 | 0 | 48.2 | 0/0 | 0 | 3689 | 358 | 1179 |
|
Chip 12
|
A
|
0 | 0 | 99.83 | 99.56 | 0.14 | 145.2 | 0 | 48.2 | 0/0 | 0 | 3645 | 365 | 1209 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.48 | 0.27 | 199.0 | 0 | 64.8 | 0/0 | 0 | 3695 | 363 | 1265 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.56 | 0.34 | 231.8 | 0 | 75.4 | 0/0 | 0 | 3647 | 360 | 1182 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.54 | 0.36 | 274.3 | 0 | 88.8 | 0/0 | 0 | 3626 | 407 | 1853 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-14 | |
| TestTime | Test Time | 09:30 | |
| TestDuration | Duration | 0:38:11 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
v1.1.1-1-g54fa876 on branch master
