Test Date: 2016-11-14 13:22
Analysis date: 2016-11-14 14:05
Analysis date: 2016-11-14 14:05
M1133 XRayHRQualification
Summary
| Module | Module | M1133 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 6 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.56 | % |
| Noise | Mean Noise | 365 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
4 | 0 | 99.80 | 99.47 | 0.37 | 214.1 | 0 | 71.9 | 0/0 | 0 | 3669 | 359 | 1149 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.55 | 0.24 | 185.6 | 0 | 61.6 | 0/0 | 0 | 3735 | 319 | 597 |
|
Chip 2
|
A
|
0 | 0 | 99.80 | 99.55 | 0.34 | 235.1 | 0 | 79.4 | 0/0 | 0 | 3683 | 349 | 997 |
|
Chip 3
|
A
|
0 | 0 | 99.82 | 99.63 | 0.2 | 166.5 | 0 | 56.3 | 0/0 | 0 | 3764 | 319 | 625 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 99.54 | 0.26 | 186.1 | 0 | 61.3 | 0/0 | 0 | 3779 | 356 | 1173 |
|
Chip 5
|
A
|
1 | 0 | 99.82 | 99.61 | 0.27 | 229.2 | 1 | 75.9 | 0/0 | 0 | 3678 | 361 | 1162 |
|
Chip 6
|
A
|
0 | 0 | 99.83 | 99.57 | 0.38 | 278.6 | 0 | 93.3 | 0/0 | 0 | 3606 | 387 | 1582 |
|
Chip 7
|
A
|
0 | 0 | 99.81 | 99.57 | 0.39 | 247.3 | 0 | 84.7 | 0/0 | 0 | 3687 | 351 | 1027 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.55 | 0.33 | 342.2 | 0 | 114.2 | 0/0 | 0 | 3663 | 393 | 1738 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.53 | 0.37 | 302.0 | 0 | 100.0 | 0/0 | 0 | 3642 | 383 | 1538 |
|
Chip 10
|
A
|
0 | 0 | 99.80 | 99.53 | 0.37 | 297.2 | 0 | 98.8 | 0/0 | 0 | 3570 | 403 | 1820 |
|
Chip 11
|
A
|
0 | 0 | 99.83 | 99.64 | 0.18 | 213.3 | 0 | 72.1 | 0/0 | 0 | 3706 | 362 | 1188 |
|
Chip 12
|
A
|
0 | 0 | 99.83 | 99.60 | 0.2 | 177.8 | 0 | 59.1 | 0/0 | 0 | 3672 | 344 | 949 |
|
Chip 13
|
A
|
0 | 0 | 99.81 | 99.53 | 0.34 | 267.6 | 0 | 89.4 | 0/0 | 0 | 3356 | 388 | 1560 |
|
Chip 14
|
A
|
1 | 0 | 99.81 | 99.54 | 0.35 | 261.7 | 0 | 88.3 | 0/0 | 0 | 3675 | 377 | 1468 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.60 | 0.31 | 256.9 | 0 | 87.2 | 0/0 | 0 | 3652 | 381 | 1497 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-14 | |
| TestTime | Test Time | 13:22 | |
| TestDuration | Duration | 0:38:23 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
v1.1.1-1-g54fa876 on branch master
