Test Date: 2016-11-14 12:16
Analysis date: 2016-11-14 13:35
Analysis date: 2016-11-14 13:35
M1132 XRayHRQualification
Summary
| Module | Module | M1132 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 0 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.56 | % |
| Noise | Mean Noise | 374 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.54 | 0.36 | 282.3 | 0 | 93.3 | 0/0 | 0 | 3595 | 403 | 1807 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.55 | 0.28 | 275.0 | 0 | 90.5 | 0/0 | 0 | 3518 | 427 | 2162 |
|
Chip 2
|
A
|
0 | 0 | 99.84 | 99.60 | 0.28 | 227.4 | 0 | 74.7 | 0/0 | 0 | 3648 | 368 | 1289 |
|
Chip 3
|
A
|
0 | 0 | 99.83 | 99.54 | 0.33 | 182.4 | 0 | 60.7 | 0/0 | 0 | 3637 | 358 | 1213 |
|
Chip 4
|
A
|
0 | 0 | 99.83 | 99.42 | 0.18 | 135.4 | 0 | 45.4 | 0/0 | 0 | 3728 | 326 | 743 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.69 | 0.21 | 175.9 | 0 | 58.4 | 0/0 | 0 | 3640 | 368 | 1262 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 99.40 | 0.24 | 176.2 | 0 | 58.7 | 0/0 | 0 | 3629 | 360 | 1201 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.61 | 0.28 | 170.0 | 0 | 56.6 | 0/0 | 0 | 3633 | 365 | 1265 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.62 | 0.21 | 162.8 | 0 | 52.9 | 0/0 | 0 | 3686 | 368 | 1329 |
|
Chip 9
|
A
|
0 | 0 | 99.80 | 99.68 | 0.3 | 165.8 | 0 | 54.5 | 0/0 | 0 | 3624 | 399 | 1710 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.58 | 0.2 | 175.2 | 0 | 57.7 | 0/0 | 0 | 3452 | 346 | 1021 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.51 | 0.15 | 144.6 | 0 | 48.6 | 0/0 | 0 | 3434 | 364 | 1261 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 99.60 | 0.25 | 133.4 | 0 | 45.0 | 0/0 | 0 | 3707 | 333 | 799 |
|
Chip 13
|
A
|
0 | 0 | 99.80 | 99.51 | 0.34 | 235.2 | 0 | 77.5 | 0/0 | 0 | 3503 | 418 | 1996 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 99.57 | 0.29 | 224.9 | 0 | 74.6 | 0/0 | 0 | 3619 | 381 | 1448 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.58 | 0.41 | 274.4 | 0 | 89.2 | 0/0 | 0 | 3554 | 405 | 1763 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-14 | |
| TestTime | Test Time | 12:16 | |
| TestDuration | Duration | 0:38:30 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
