Test Date: 2016-11-14 09:30
Analysis date: 2016-11-14 10:19
Analysis date: 2016-11-14 10:19
M1131 XRayHRQualification
Summary
| Module | Module | M1131 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 17 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 17 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.59 | % |
| Noise | Mean Noise | 381 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.80 | 99.63 | 0.32 | 218.0 | 0 | 72.4 | 0/0 | 0 | 3584 | 387 | 1586 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.70 | 0.3 | 213.6 | 0 | 70.1 | 0/0 | 0 | 3632 | 371 | 1283 |
|
Chip 2
|
A
|
0 | 0 | 99.81 | 99.55 | 0.28 | 229.7 | 0 | 76.4 | 0/0 | 0 | 3609 | 391 | 1684 |
|
Chip 3
|
A
|
0 | 0 | 99.82 | 99.53 | 0.25 | 183.5 | 0 | 61.8 | 0/0 | 0 | 3632 | 375 | 1389 |
|
Chip 4
|
A
|
0 | 0 | 99.84 | 99.63 | 0.19 | 181.7 | 0 | 59.7 | 0/0 | 0 | 3661 | 384 | 1551 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.61 | 0.27 | 232.5 | 0 | 78.7 | 0/0 | 0 | 3673 | 363 | 1195 |
|
Chip 6
|
A
|
0 | 0 | 99.81 | 99.61 | 0.31 | 274.7 | 0 | 90.7 | 0/0 | 0 | 3663 | 392 | 1700 |
|
Chip 7
|
A
|
0 | 0 | 99.84 | 99.58 | 0.29 | 285.4 | 0 | 94.0 | 0/0 | 0 | 3535 | 384 | 1562 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.57 | 0.33 | 285.2 | 0 | 94.9 | 0/0 | 0 | 3681 | 371 | 1388 |
|
Chip 9
|
A
|
17 | 0 | 99.80 | 99.54 | 0.31 | 290.4 | 0 | 95.7 | 0/0 | 0 | 3465 | 402 | 1736 |
|
Chip 10
|
A
|
0 | 0 | 99.80 | 99.54 | 0.36 | 293.1 | 0 | 96.7 | 0/0 | 0 | 3598 | 394 | 1688 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.59 | 0.32 | 192.9 | 0 | 63.9 | 0/0 | 0 | 3630 | 355 | 1102 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.56 | 0.23 | 182.4 | 0 | 61.0 | 0/0 | 0 | 3554 | 399 | 1769 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.57 | 0.28 | 233.9 | 0 | 77.9 | 0/0 | 0 | 3624 | 362 | 1186 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 99.66 | 0.26 | 226.6 | 0 | 74.2 | 0/0 | 0 | 3585 | 382 | 1539 |
|
Chip 15
|
A
|
0 | 0 | 99.81 | 99.56 | 0.28 | 236.5 | 0 | 79.1 | 0/0 | 0 | 3626 | 378 | 1453 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-14 | |
| TestTime | Test Time | 09:30 | |
| TestDuration | Duration | 0:38:11 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 13 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
v1.1.1-1-g54fa876 on branch master
