Test Date: 2016-11-14 12:16
Analysis date: 2016-11-15 16:02
Analysis date: 2016-11-15 16:02
M1130 XRayHRQualification
| Comment | Comment | comment.txt: Cluster of hot pixels on C15 |
Summary
| Module | Module | M1130 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | C | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.81/99.56 | % |
| Noise | Mean Noise | 381 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 99.59 | 0.29 | 212.6 | 0 | 71.0 | 0/0 | 0 | 3629 | 391 | 1654 |
|
Chip 1
|
A
|
0 | 0 | 99.80 | 99.40 | 0.38 | 204.3 | 0 | 67.2 | 0/0 | 0 | 3613 | 377 | 1422 |
|
Chip 2
|
A
|
0 | 0 | 99.80 | 99.56 | 0.26 | 248.5 | 0 | 81.6 | 0/0 | 0 | 3482 | 433 | 2220 |
|
Chip 3
|
A
|
0 | 0 | 99.81 | 99.56 | 0.28 | 171.8 | 0 | 57.5 | 0/0 | 0 | 3621 | 380 | 1503 |
|
Chip 4
|
A
|
0 | 0 | 99.81 | 99.53 | 0.22 | 175.5 | 0 | 58.6 | 0/0 | 0 | 3541 | 407 | 1876 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.54 | 0.29 | 223.1 | 0 | 74.6 | 0/0 | 0 | 3697 | 349 | 996 |
|
Chip 6
|
A
|
0 | 0 | 99.83 | 99.61 | 0.29 | 236.3 | 0 | 77.5 | 0/0 | 0 | 3640 | 386 | 1539 |
|
Chip 7
|
A
|
0 | 0 | 99.85 | 99.65 | 0.24 | 223.9 | 0 | 73.4 | 0/0 | 0 | 3664 | 378 | 1457 |
|
Chip 8
|
A
|
0 | 0 | 99.82 | 99.51 | 0.35 | 271.8 | 0 | 89.1 | 0/0 | 0 | 3579 | 416 | 1996 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.57 | 0.42 | 225.9 | 0 | 74.4 | 0/0 | 0 | 3667 | 355 | 1125 |
|
Chip 10
|
A
|
1 | 0 | 99.82 | 99.57 | 0.31 | 267.6 | 0 | 88.9 | 0/0 | 0 | 3623 | 391 | 1636 |
|
Chip 11
|
A
|
0 | 0 | 99.83 | 99.60 | 0.31 | 186.5 | 0 | 60.9 | 0/0 | 0 | 3687 | 357 | 1130 |
|
Chip 12
|
A
|
0 | 0 | 99.84 | 99.62 | 0.24 | 166.7 | 0 | 54.7 | 0/0 | 0 | 3671 | 355 | 1118 |
|
Chip 13
|
A
|
0 | 0 | 99.80 | 99.52 | 0.24 | 232.8 | 0 | 77.5 | 0/0 | 0 | 3603 | 381 | 1458 |
|
Chip 14
|
A
|
0 | 0 | 99.80 | 99.62 | 0.25 | 203.8 | 0 | 67.8 | 0/0 | 0 | 3560 | 379 | 1459 |
|
Chip 15
|
A
|
0 | 0 | 99.77 | 99.56 | 0.63 | 212.4 | 0 | 70.6 | 0/0 | 0 | 3629 | 360 | 1144 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-14 | |
| TestTime | Test Time | 12:16 | |
| TestDuration | Duration | 0:38:30 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
v1.1.1-1-g54fa876 on branch master
