Test Date: 2016-11-14 11:37
Analysis date: 2016-11-14 12:21
Analysis date: 2016-11-14 12:21
M1129 XRayHRQualification
Summary
| Module | Module | M1129 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 3 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.55 | % |
| Noise | Mean Noise | 370 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.79 | 99.48 | 0.5 | 249.4 | 0 | 80.0 | 0/0 | 0 | 3562 | 418 | 2053 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.60 | 0.31 | 209.8 | 0 | 67.2 | 0/0 | 0 | 3609 | 389 | 1632 |
|
Chip 2
|
A
|
0 | 0 | 99.81 | 99.52 | 0.41 | 237.8 | 0 | 77.4 | 0/0 | 0 | 3600 | 403 | 1833 |
|
Chip 3
|
A
|
0 | 0 | 99.83 | 99.61 | 0.18 | 132.9 | 0 | 43.7 | 0/0 | 0 | 3761 | 317 | 673 |
|
Chip 4
|
A
|
1 | 0 | 99.82 | 99.74 | 0.13 | 119.8 | 1 | 39.2 | 0/0 | 0 | 3694 | 345 | 968 |
|
Chip 5
|
A
|
0 | 0 | 99.81 | 99.47 | 0.3 | 156.5 | 0 | 50.4 | 0/0 | 0 | 3658 | 372 | 1363 |
|
Chip 6
|
A
|
0 | 0 | 99.83 | 99.46 | 0.19 | 139.1 | 0 | 45.4 | 0/0 | 0 | 3706 | 352 | 1010 |
|
Chip 7
|
A
|
0 | 0 | 99.83 | 99.25 | 0.24 | 136.6 | 0 | 44.5 | 0/0 | 0 | 3704 | 349 | 964 |
|
Chip 8
|
A
|
1 | 0 | 99.81 | 99.55 | 0.24 | 145.8 | 1 | 47.5 | 0/0 | 0 | 3739 | 350 | 1096 |
|
Chip 9
|
A
|
0 | 0 | 99.80 | 99.63 | 0.26 | 162.5 | 0 | 52.6 | 0/0 | 0 | 3639 | 383 | 1533 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.56 | 0.3 | 171.3 | 0 | 55.6 | 0/0 | 0 | 3373 | 402 | 1788 |
|
Chip 11
|
A
|
1 | 0 | 99.83 | 99.66 | 0.16 | 118.5 | 1 | 38.9 | 0/0 | 0 | 3725 | 324 | 701 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.55 | 0.24 | 144.3 | 0 | 47.8 | 0/0 | 0 | 3641 | 363 | 1304 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.57 | 0.29 | 234.2 | 0 | 75.4 | 0/0 | 0 | 3631 | 387 | 1608 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.55 | 0.35 | 189.2 | 0 | 61.1 | 0/0 | 0 | 3601 | 385 | 1595 |
|
Chip 15
|
A
|
0 | 0 | 99.83 | 99.56 | 0.31 | 229.2 | 0 | 72.7 | 0/0 | 0 | 3385 | 386 | 1567 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-14 | |
| TestTime | Test Time | 11:37 | |
| TestDuration | Duration | 0:37:7 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 91856 | |
| nWarnings | # Warnings | 546 | |
| channel_0_count | Channel 0 | 18 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 550 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 191 | |
| message_tokenchain_count | Token Chain Length | 18 | |
| message_readback_count | Readback start marker | 359 |
