Test Date: 2016-11-14 11:37
Analysis date: 2016-11-14 13:31
Analysis date: 2016-11-14 13:31
M1128 XRayHRQualification
Summary
| Module | Module | M1128 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 1 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 150/300 | 99.82/99.55 | % |
| Noise | Mean Noise | 377 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.83 | 99.62 | 0.21 | 209.6 | 0 | 69.2 | 0/0 | 0 | 3702 | 352 | 1098 |
|
Chip 1
|
A
|
0 | 0 | 99.81 | 99.55 | 0.3 | 220.8 | 0 | 73.0 | 0/0 | 0 | 3611 | 373 | 1380 |
|
Chip 2
|
A
|
0 | 0 | 99.84 | 99.44 | 0.25 | 195.2 | 0 | 64.8 | 0/0 | 0 | 3442 | 375 | 1400 |
|
Chip 3
|
A
|
0 | 0 | 99.82 | 99.36 | 0.33 | 154.9 | 0 | 52.5 | 0/0 | 0 | 3688 | 350 | 1004 |
|
Chip 4
|
A
|
0 | 0 | 99.79 | 99.53 | 0.33 | 163.9 | 0 | 55.0 | 0/0 | 0 | 3697 | 365 | 1260 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 99.53 | 0.29 | 242.9 | 0 | 78.3 | 0/0 | 0 | 3682 | 371 | 1371 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 99.54 | 0.23 | 238.3 | 0 | 78.5 | 0/0 | 0 | 3621 | 401 | 1769 |
|
Chip 7
|
A
|
0 | 0 | 99.82 | 99.51 | 0.24 | 273.7 | 0 | 91.3 | 0/0 | 0 | 3680 | 393 | 1646 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.52 | 0.41 | 308.7 | 0 | 102.6 | 0/0 | 0 | 3616 | 430 | 2234 |
|
Chip 9
|
A
|
0 | 0 | 99.81 | 99.59 | 0.36 | 246.1 | 0 | 81.4 | 0/0 | 0 | 3644 | 390 | 1601 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.51 | 0.35 | 246.2 | 0 | 81.9 | 0/0 | 0 | 3631 | 389 | 1624 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 99.61 | 0.18 | 147.8 | 0 | 49.3 | 0/0 | 0 | 3752 | 329 | 758 |
|
Chip 12
|
A
|
0 | 0 | 99.83 | 99.62 | 0.21 | 171.9 | 0 | 57.2 | 0/0 | 0 | 3654 | 380 | 1445 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.61 | 0.3 | 241.7 | 0 | 79.2 | 0/0 | 0 | 3629 | 387 | 1582 |
|
Chip 14
|
A
|
0 | 0 | 99.80 | 99.50 | 0.28 | 219.9 | 0 | 72.4 | 0/0 | 0 | 3616 | 391 | 1641 |
|
Chip 15
|
C
|
1 | 0 | 99.81 | 99.71 | 0.24 | 203.1 | 0 | 65.9 | 0/0 | 2 | 3683 | 356 | 1120 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-14 | |
| TestTime | Test Time | 11:37 | |
| TestDuration | Duration | 0:37:7 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
v1.1.1-1-g54fa876 on branch master
